Mean Well GSM12U15-P1J Power Supply 12W 15V
Description
Description
Features
| Universal AC input / Full range |
| Energy efficiency level VI |
| Medical safety approved (2 x MOPP) |
| Extremely low leakage current |
| No load power consumption < 0.075W(<0.1W for 18V/48V) |
| High efficiency up to 87% |
| Class II power (without earth pin) |
| Protections: Short circuit / Overload / Over voltage |
| Fully enclosed plastic case |
| 100% full load burn-in test |
| 3 years warranty |
General Specification
| AC input voltage range | 80~264VAC ; 113~370VDC |
| AC inrush current (max.) | Cold start, 60A at 230VAC |
| Overload protection | 110%~140% rated output voltage, hiccup mode, auto-recovery |
| Withstand voltage | I/P-O/P: 5656VDC |
| Working temperature | -20~+70°C |
| Safety standards | ANSI/AAMI ES60601-1/ES60601-1-1-11 |
| EMC standards | FCC part 15/CISPR22 Class B |
| Length of output cable | 100cm of UL2468, 18AWG for 5~7.5V; 120cm of UL2468, 22AWG for 9V; 180cm of UL2468, 24AWG for 12V~48V |
| Dimension (LxWxH) | 62.2 x 27.4 x 45.5mm |
| Standard DC plug | P1J: 2.1øx5.5øx11mm / C+, tuning fork type |
| packing | 110pcs/13Kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesGSM Series
-
Power Rating12 Watt
-
Output Voltage15 Volt
-
Rated Current0.8 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetEAC,FCC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length2.45 in
-
Width1.79 in
-
Height1.08 in
-
Weight0.24 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the GSM12U15-P1J to power a small 15V industrial controller?
Yes, this model is a constant-voltage 15V power supply rated for 12W and 0.8A. It fits low-power industrial control devices that specifically require a regulated 15V DC input and stay within that 0.8A output limit.
Is this power supply suitable for a 15V embedded system or electronics prototype?
It can be a fit for embedded or bench-built equipment that needs 15V constant voltage and no more than 12W total load. The wide 80-264VAC input also makes it practical where AC input conditions may vary across sites or regions.
Can this 15V adapter be used for low-power automation sensors or interface modules?
It is appropriate for 15V automation accessories or interface modules as long as the combined load does not exceed 0.8A at 15V. Because it is a constant-voltage unit, it is intended for equipment designed to accept a fixed 15V DC supply.
Would this work for a compact 15V lab or test fixture?
Yes, it suits compact test fixtures or light-duty electronics that call for 15V DC and stay within the 12W rating. Its small 62.2 × 45.5 × 27.4 mm housing also helps where space is limited.
Is the GSM12U15-P1J suitable for outdoor use or harsh ambient conditions?
No IP rating is listed in the provided specs, so it should be treated as a supply for dry, protected environments unless the final equipment provides its own enclosure. Its stated operating temperature range is -20°C to +70°C, which supports a broad indoor operating window.
