Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well HEP-100-36 Power Supply 95.4W 36V

Name: Mean Well HEP-100-36 Power Supply 95.4W 36V
Brand: Mean Well
SKU: HEP-100-36
Price: 96.62 USD
Availability: InStock

$96.62 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

Universal AC input (up to 305VAC) / Full range

High efficiency up to 93%

Built-in active PFC function

Protections: Short circuit / Over current / Over voltage / Over temperature

IP65 design, optional IP68 rated model available

Cooling by free air convection

Meet 6KV surge immunity level

Aluminum case and filling with heat-conducted glue

Withstand 10G vibration test

Operating altitude up to 5000 meters

6 years warranty

General Specification

AC input voltage range	85~264VAC ; 120~370VDC
AC inrush current (max.)	Cold start, 60A at 230VAC
DC adjustment range	-10%~+10% rated output voltage (A-Type only)
Current adjustment range	60%~100%
Over current protection	105%~125% constant current limiting, auto-recovery
Over voltage protection	105%~135% rated output voltage
Setup, rise, hold up time	500ms, 50ms, 16ms at full load and 230VAC
Withstand voltage	I/P-O/P: 3.75KVAC, I/P-FG: 2KVAC, O/P-FG: 1.5KVAC
Working temperature	-55~+70ºC (refer to output derating curve)
Safety standards	UL62368-1, IEC62368-1 approved
EMC standards	EN55022 class B, EN61000-3-2,3, EAC TP TC 020
Connection Input	SJTW 18AWGx3C(30cm)
Connection Output	SJTW 14AWGx2C (30cm)+ SJTW 14AWGx2C (30cm)
Dimension (LxWxH) (mm)	226x 68 x 38.8

Specifications

Brand

Mean Well
Series

HEP Series
Power Rating

95.4 Watt
Output Voltage

36 Volt
Rated Current

2.65 Ampere
Input Voltage

90V~305V
No of Output

1
Standards Met

CB,CE,EAC,UL
Operation Mode

Constant Voltage
Operating Temperature

-55°C~70°C
Warranty

6 Year
Length

8.66 in
Width

2.68 in
Height

1.53 in
Weight

2.47 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Features

Universal AC input (up to 305VAC) / Full range

High efficiency up to 93%

Built-in active PFC function

Protections: Short circuit / Over current / Over voltage / Over temperature

IP65 design, optional IP68 rated model available

Cooling by free air convection

Meet 6KV surge immunity level

Aluminum case and filling with heat-conducted glue

Withstand 10G vibration test

Operating altitude up to 5000 meters

6 years warranty

General Specification

AC input voltage range

85~264VAC ; 120~370VDC

AC inrush current (max.)

Cold start, 60A at 230VAC

DC adjustment range

-10%~+10% rated output voltage (A-Type only)

Current adjustment range

60%~100%

Over current protection

105%~125% constant current limiting, auto-recovery

Over voltage protection

105%~135% rated output voltage

Setup, rise, hold up time

500ms, 50ms, 16ms at full load and 230VAC

Withstand voltage

I/P-O/P: 3.75KVAC, I/P-FG: 2KVAC, O/P-FG: 1.5KVAC

Working temperature

-55~+70ºC (refer to output derating curve)

Safety standards

UL62368-1, IEC62368-1 approved

EMC standards

EN55022 class B, EN61000-3-2,3, EAC TP TC 020

Connection Input

SJTW 18AWGx3C(30cm)

Connection Output

SJTW 14AWGx2C (30cm)+ SJTW 14AWGx2C (30cm)

Dimension (LxWxH) (mm)

226x 68 x 38.8
