Mean Well HEP-100-54 Power Supply 95.58W 54V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-100-54 Power Supply 95.58W 54V
The HEP-100 is a 100W Mean Well DIN rail power converter with a 220mm profile (input range: 90~305VAC, operating temperature: -55~+70℃).
Key Features
- ✓ 220mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -55~+70℃
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1 , IEC/EN62368-1,IP65 (or IP68 for HEP-100 Blank type) , EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating95.58 Watt
-
Output Voltage54 Volt
-
Rated Current1.77 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.66 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.47 lb
::specification::
Frequently Asked Questions
Can I use the HEP-100-54 for 54V telecom or network equipment?
Yes, if the equipment is specified for 54V DC input and the total load remains within 95.58W and 1.77A. This is a constant-voltage model, so it is intended for equipment that expects a regulated 54V supply.
Is the HEP-100-54 suitable for 54V automation or monitoring devices?
It can be suitable for lower-power 54V automation equipment as long as the load does not exceed 1.77A or 95.58W. The wide operating temperature range of -55°C to +70°C supports use in demanding industrial settings.
Can this power supply run 54V LED or display systems?
Yes, for 54V constant-voltage loads whose total draw stays at or below 95.58W. The fanless design and efficiency up to 96% are useful where heat buildup and moving parts are concerns.
Is the HEP-100-54 appropriate for outdoor and harsh-environment use?
This version is rated IP68, which makes it better suited to exposed outdoor, wet, or dusty environments than the IP65 variant. It also uses a rugged metal case and is specified to withstand 10G vibration.
What are the HEP-100 alternatives if I am comparing 54V to other outputs?
Within the HEP-100 range, the output choices are 12V at 100.08W and 8.34A, 15V at 100.05W and 6.67A, 24V at 96W and 4A, 36V at 95.4W and 2.65A, 48V at 96W and 2A, and 54V at 95.58W and 1.77A. The HEP-100-54 and HEP-100-54A share the same 95.58W, 54V, 1.77A output rating.
