Mean Well HEP-185-12 Power Supply 156W 12V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-185-12 Power Supply 156W 12V
The HEP-185 is a 185W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC).
Key Features
- ✓ 228mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-185 Blank type), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating156 Watt
-
Output Voltage12 Volt
-
Rated Current13 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can I use the HEP-185-12 for a 12V industrial control panel or automation system?
Yes, this is a 12V constant-voltage supply rated for 156W and 13A. It fits 12V DC control or automation equipment that stays within those output limits.
Is the HEP-185-12 suitable for 12V CCTV, access control, or security hardware?
It can support 12V security or access-control equipment when the total load does not exceed 156W or 13A. Its wide 90-305VAC input also helps in sites with varied AC input conditions.
Can this model power 12V embedded electronics in a sealed or washdown environment?
Yes, the HEP-185-12 is listed here as IP68, which makes it the more sealed option in this group. Combined with the fanless design and -55°C to +70°C operating range, it is suited to demanding indoor or outdoor environments.
Is the HEP-185-12 appropriate for outdoor 12V equipment exposed to weather?
For applications that need a higher ingress rating, this version is better suited because it is specified as IP68. It also uses a rugged metal case and is rated to withstand 10G vibration for harsh-environment deployment.
How does the HEP-185-12 compare with other 12V HEP power supplies?
In the 12V range, the HEP-100-12 and HEP-100-12A are 100.08W at 8.34A, the HEP-150-12 and HEP-150-12A are 150W at 12.5A, this HEP-185-12 and the HEP-185-12A are 156W at 13A, the HEP-240-12 and HEP-240-12A are 192W at 16A, the HEP-320-12 and HEP-320-12A are 264W at 22A, and the HEP-600-12 and HEP-600-12A are 480W at 40A. The HEP-600C-12 is a different variant at 14.4V, rated for 600W and 35A.
