Mean Well HVG-100-30B Power Supply 100W 30V - Dimmable
The HVG-100 is a 100W Mean Well power converter (input range: 180~528VAC).
Key Features
- ✓ Input voltage range: 180~528VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes UL8750(type”HL”), CSA C22.2 No. 250.0-08, EAC TP TC 004 IP65 or IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVG Series
-
Power Rating96 Watt
-
Output Voltage30 Volt
-
Rated Current3.2 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Resistance
-
Standards MetEAC,FCC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length9.29 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.6 lb
::specification::
Frequently Asked Questions
Can I use the HVG-100-30B for 30V LED strip lighting in outdoor signage?
Yes, it is a 30V, 96W driver and can support 30V LED strip or signage loads that stay within 3.2A. Its IP67 waterproof rating makes it a stronger fit for outdoor sign environments where water exposure is possible.
Is this power supply suitable for 30V exterior architectural lighting?
It can be used for 30V architectural accent or facade lighting if the total connected load stays within 96W. The IP67 waterproof enclosure and -40°C to +90°C operating temperature range support demanding outdoor conditions.
Can the HVG-100-30B run 30V lighting in washdown or wet-area environments?
Yes, this is the better fit among the 30V options when the installation environment is wet, because it is rated IP67 waterproof. The load still needs to match 30V and remain within 96W and 3.2A.
How do I size 30V LED strip length with this driver?
Take the maximum output power of 96W and divide it by the strip's wattage per meter. That gives the theoretical maximum length, but you should check your strip rated power per meter before selecting the final run length.
What makes the HVG-100-30B different from other 30V HVG-100 models?
The HVG-100-30A, HVG-100-30AB, and HVG-100-30B are all listed at 96W, 30V, and 3.2A, while the HVG-100-30D is listed at 75W. This specific model is identified with an IP67 waterproof rating, which distinguishes it from the IP65 water-resistant 30V variants shown here.
