Mean Well HVGC-100-700B Power Supply 100W 700mA - Dimmable
The HVGC-100 is a 100W Mean Well DIN rail power converter with a 236mm profile (input range: 180~528VAC).
Key Features
- ✓ 236mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~528VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: , UL8750 CSA C22.2 No. 250.0-08, TUV EN61347-1, EN61347-2-13, design refer to UL60950-1, TUV EN60950-1 EAC TP TC 004 IP65 or IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVGC Series
-
Power Rating99.4 Watt
-
Output Voltage142 Volt
-
Rated Current0.7 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CE,EAC,FCC,TUV,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length9.29 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.6 lb
::specification::
Frequently Asked Questions
Can I use the HVGC-100-700B for 700mA LED downlights?
Yes, this driver is designed for constant current operation at 700mA, which matches LED downlights that require a 700mA driver. The connected LED load also needs to stay within the 15-142V constant current range and within the 99.4W power rating.
Is this driver suitable for signage modules that run on constant current instead of constant voltage?
It can be used for signage modules only if the modules are specified for constant current at 700mA. This is not a constant voltage power supply, so it is not the right choice for signage modules that expect a fixed voltage output.
Can the HVGC-100-700B power a small LED array for outdoor use?
Yes, it can support a small LED array when the array is designed for 700mA constant current and falls within the 15-142V CC range. Its IP67 waterproof rating also makes it suitable for wet or exposed environments.
How do I know if my LED load is compatible with this 700mA driver?
The LED load must be rated for constant current at 700mA, and the total forward voltage must fall within the 15-142V constant current output range. The exact number of LEDs depends on the forward voltage of each LED, so it should not be sized by LED count alone.
What are the differences between the HVGC-100-700B and the other HVGC-100 700mA or 350mA versions?
Within the HVGC-100 family, the 700mA versions are HVGC-100-700A, HVGC-100-700AB, and HVGC-100-700B, and each is rated at 99.4W with a 15-142V CC range. The 350mA versions are HVGC-100-350A, HVGC-100-350AB, and HVGC-100-350B, and each is rated at 99.75W with a 29-285V CC range.
