Mean Well IRM-01-12 Switching Power Supply 1W 12V 83mA - Encapsulated
The IRM-01 is a 1W Mean Well power converter (input range: 85~305VAC).
Key Features
- ✓ Input voltage range: 85~305VAC
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesIRM Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.08 Ampere
-
Input Voltage85V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length1.33 in
-
Width0.87 in
-
Height0.59 in
-
Weight0.05 lb
::specification::
Frequently Asked Questions
Can I use the IRM-01-12 for a small 12V industrial control circuit?
Yes, if the control circuit needs a constant 12V DC supply and stays within the 1W, 0.08A output limit. It is a better fit for low-power industrial monitoring, interface, or control electronics than for heavier 12V loads.
Is the IRM-01-12 suitable for an embedded 12V sensor or alarm board?
It can work for compact embedded 12V boards that use constant voltage and draw no more than 0.08A from a 1W supply. The miniature encapsulated design and 33.7 × 22.2 × 15.0 mm size also suit tight board-level space.
Can this power a low-draw 12V auxiliary rail in IT or telecom equipment?
It is appropriate for very low-power 12V auxiliary rails where the load stays within 1W and 0.08A. Buyers should treat it as a small constant voltage supply for board-level support functions, not for higher-current 12V equipment.
How does the IRM-01-12 compare with other low-power IRM models?
In the 1W IRM-01 group, sibling outputs are 3.3V 300A, 5V 200A, 9V 111A, 12V 0.08A, 15V 0.07A, and 24V 0.04A, and each output also has an S version. If you need more output at 12V, the broader IRM series also includes 2W 167A, 3W 250A, 5.04W 0.42A, 10.2W 0.85A, 15W 1.25A, 21.6W 1.8A, 30W 2.5A, 45.6W 3.8A, 60W 5A, and 80.4W 6.7A options.
Is the IRM-01-12 suitable for outdoor or harsh-temperature use?
The operating temperature range is -30°C to +85°C, so the temperature spec is broad for industrial environments. An IP rating is not listed, so indoor or outdoor exposure suitability is not specified by the provided specs.
