Mean Well IRM-02-15S Switching Power Supply 2W 15V 133mA - Encapsul...
The IRM-02 is a 2W Mean Well power converter (input range: 85~305VAC).
Key Features
- ✓ Input voltage range: 85~305VAC
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesIRM Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.13 Ampere
-
Input Voltage85V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length1.33 in
-
Width0.87 in
-
Height0.63 in
-
Weight0.05 lb
::specification::
Frequently Asked Questions
Can I use the IRM-02-15S in a compact 15V embedded or automation board?
Yes, if the board requires a 15V constant-voltage supply and total draw stays within 2W and 133mA. The SMD style and 33.7 × 22.2 × 16.0 mm package make it suitable for dense internal designs.
Is the IRM-02-15S suitable for low-power 15V industrial monitoring electronics?
It can work for small monitoring or interface electronics that need 15V and stay below 133mA. Loads above the 2W rating need a larger 15V model from the same series.
Can this power supply be used where the AC input may vary across regions?
Yes, the input is rated 85-305VAC, so it supports a wide AC range. On the DC side, it remains a 15V constant-voltage supply with a 2W maximum output.
Does the IRM-02-15S support outdoor or washdown use?
Its operating temperature range is -30°C to +85°C, which is broad for enclosed equipment. Since no IP rating is listed in the supplied specs, it should be treated as an indoor protected component rather than an outdoor-rated unit.
What are the main differences between IRM-02-15S and other 15V IRM options?
The 15V family spans 1W at 0.07A, 2W at 133mA, 3W at 200mA, 4.95W at 0.33A, 10.05W at 0.67A, 15W at 1A, 21W at 1.4A, 30W at 2A, 45W at 3A, 60W at 4A, and 85.05W at 5.67A. At the 2W level, IRM-02-15 is the PCB mounting style version and IRM-02-15S is the SMD style version, both rated 15V and 133mA.
