Mean Well IRM-02-24S Switching Power Supply 2W 24V 83mA - Encapsulated
The IRM-02 is a 2W Mean Well power converter (input range: 85~305VAC).
Key Features
- ✓ Input voltage range: 85~305VAC
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesIRM Series
-
Power Rating2 Watt
-
Output Voltage24 Volt
-
Rated Current0.08 Ampere
-
Input Voltage85V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length1.33 in
-
Width0.87 in
-
Height0.63 in
-
Weight0.05 lb
::specification::
Frequently Asked Questions
Can I use the IRM-02-24S in a surface-mount automation board that needs 24V DC?
Yes, this version provides 24V constant-voltage output at 2W and 0.08A with an 85-305VAC input range. Its SMD style makes it relevant for compact 24V automation or control boards designed around surface-mount assembly.
Is the IRM-02-24S appropriate for powering a low-power 24V monitoring or alarm circuit?
It can be appropriate for low-power 24V monitoring, alarm, or signaling electronics that stay within the 2W and 0.08A output limit. It is intended for small constant-voltage DC loads rather than heavier 24V field devices.
Can this model power a compact 24V embedded control module from worldwide AC input?
Yes, the 85-305VAC input range supports equipment intended for varied AC supply conditions, while the output remains 24V constant voltage. It is best suited to compact embedded modules whose 24V demand stays within 2W and 0.08A.
What is the difference between IRM-02-24S and the other low-power IRM 24V models?
Within the sibling list, the 24V options are IRM-01-24 at 1W, 24V, 0.04A; IRM-01-24S at 1W, 24V, 0.04A; IRM-02-24 at 2W, 24V, 0.08A; IRM-02-24S at 2W, 24V, 0.08A; IRM-03-24 at 3W, 24V, 125A; IRM-03-24S at 3W, 24V, 125A; IRM-05-24 at 5.52W, 24V, 0.23A; IRM-10-24 at 10.08W, 24V, 0.42A; IRM-15-24 at 15.12W, 24V, 0.63A; IRM-20-24 at 21.6W, 24V, 0.9A; IRM-30-24 at 31.2W, 24V, 1.3A; IRM-30-24ST at 31.2W, 24V, 1.3A; IRM-45-24 at 45.6W, 24V, 1.9A; IRM-45-24ST at 45.6W, 24V, 1.9A; IRM-60-24 at 60W, 24V, 2.5A; IRM-60-24ST at 60W, 24V, 2.5A; IRM-90-24 at 90W, 24V, 3.75A; and IRM-90-24ST at 90W, 24V, 3.75A. This IRM-02-24S sits in the 2W, 24V, 0.08A position and uses the SMD style package.
Can the IRM-02-24S be used in exposed outdoor equipment?
An outdoor rating is not listed for this model. The specified environmental data is -30°C to +85°C operation, and the encapsulated SMD format is more appropriate inside protected indoor assemblies than in directly exposed installations.
