Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well MDS20C-15 DC-DC Converter - 20W - 36~75V in 15V out
Description
Description
Features
| DIP 2"x1" package with international standard pinout |
| 2:1 wide input range |
| Low patient leakage current <5µA |
| Wide operating temperature range -40~+90℃ |
| Medical safety approved(2xMOPP) according to IEC60601-1 |
| No minimum load required |
| Protections: Short circuit(Continuous)/Overload/Input under voltage |
| 4000VAC high I/O isolation(Reinforced isolation) |
| 3 years warranty |
General Specification
| Voltage accuracy | ±1% |
| Efficiency | 90% |
| Short circuit protection | Continuous, automatic recovery |
| Working temperature | -40°C to +90°C |
| Temp. Coefficient | 0.03% / ℃ (0 ~ 70℃) |
| Dimension (LxWxH) (mm) | 50.8*25.4*12mm (2*1*0.47 inch) |
| Packing | 30g; 18pcs/per tube, 432pcs/24 tube max./carton |
Specifications
Specifications
-
BrandMean Well
-
SeriesMDS Series
-
Power Rating20 Watt
-
Output Voltage15 Volt
-
Rated Current1.33 Ampere
-
Input Voltage36V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length2 in
-
Width1 in
-
Height0.47 in
-
Weight0.07 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the MDS20C-15 for a 15V industrial sensor or controller powered from a 36-75VAC input?
Yes, this model is intended for a 36-75VAC input and delivers a constant 15V output. It fits low-power industrial electronics that stay within 20W and 1.33A.
Is the MDS20C-15 suitable for embedded control hardware that needs 15V and limited board space?
It is compact at 50.8 x 25.4 x 12.0 mm and weighs 0.03 kg, which helps in space-constrained embedded designs. Electrically, it provides a regulated 15V output with up to 1.33A, capped at 20W.
Can this converter support low-power automation equipment that specifically requires 15V constant voltage?
Yes, when the equipment needs constant 15V and the total draw does not exceed 1.33A or 20W. The input must also be within the specified 36-75VAC range.
Is the MDS20C-15 appropriate for cold or high-heat operating conditions?
The rated operating temperature range is -40 degrees C to +90 degrees C, so it is specified for a wide temperature span. No IP rating is provided, so the specs do not establish suitability for direct weather exposure.
What are the output differences between the MDS20C-15 and the other MDS20C versions?
Each listed model in this group is rated at 20W. The outputs are 5V at 4A for MDS20C-05, 12V at 1.67A for MDS20C-12, 15V at 1.33A for MDS20C-15, and 24V at 833A for MDS20C-24.
