Mean Well MPS-120-5 Power Supply 110W 5V he rated current is based on there being a fan that can provide 25CFM.

$95.98 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

MEAN WELL MPS-120 Series Power Supplies are 120W singlel output medical type power supplies with 3 years warranty.

Features

  • Universal AC/Full range
  • Low leakage current<180uA
  • Protections:Shortzircuit/Overload/Over voltage
  • UL60601-1 medical safety approved
  • With power good and fail signal outputOptional)
  • 100% full load burn in test
  • Fixed switching frequency at 45KHz
  • 3 years warranty

Specifications

  • Brand
    Mean Well
  • Series
    MPS Series
  • Power Rating
    110 Watt
  • Output Voltage
    5 Volt
  • Rated Current
    22 Ampere
  • Input Voltage
    90V~264V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CB,CE,TUV,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -20°C~70°C
  • Warranty
    3 Year
  • Length
    7 in
  • Width
    4.25 in
  • Height
    1.4 in
  • Weight
    1.21 lb

File Downloads

::specification::
