Description
Description
Features
Charger for lead-acid batteries (flooded, Gel and AGM) and Li-ion batteries (lithium iron and lithium manganese) |
3 stage charging |
AC 115/230VAC selected by switch |
Built-in passive PFC function compliance to BS EN/EN61000-3-2 Class A (option) |
Protection: Short circuit / Reverse polarity / Over voltage / Over temperature |
2 color LED loading indicator |
Low cost, High reliability |
2 color LED loading indicator |
FAN on/off control (Depends on charging current |
3 years warranty |
General Specification
AC input voltage range | 90 ~ 132VAC / 180 ~ 264VAC selected by switch; 127 ~ 187VDC / 254 ~ 370VDC |
AC inrush current (max.) | COLD START 60A |
Over-voltage protection | Protection type: Shut down o/p voltage, re-power on to recover |
Withstand voltage | I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
Working temperature | -20~+60ºC(refer to output derating curve) |
Safety standards | IEC60335-2-29 CB approved by TUV(except for 48V), UL62368-1, CSA C22.2 No. 62368-1, EAC TP TC 004 approved, Design refer to BS EN/EN62368-1 for P-type only |
EMC standards |
EN55022(CISPR22) Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024 |
Dimension (LxWxH) (mm) | 253 x 135 x 48.5mm |
Packing | 1.5Kg; 6pcs/10Kg/1.03CUFT |
Specifications
Specifications
-
BrandMean Well
-
SeriesPB Series
-
Power Rating360 Watt
-
Output Voltage14.4 Volt
-
Rated Current24.3 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty3 Year
-
Length9.96 in
-
Width5.32 in
-
Height1.91 in
-
Weight3.31 lb
