Mean Well RCP-1600-48 power supply 1600W 48V 33.5A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RCP-1600-48 power supply 1600W 48V 33.5A
The RCP-1600 is a 1600W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL62368-1, TUV EN62368-1 EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRCP Series
-
Power Rating1608 Watt
-
Output Voltage48 Volt
-
Rated Current33.5 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty5 Year
-
Length11.81 in
-
Width3.35 in
-
Height1.61 in
-
Weight4.12 lb
::specification::
Frequently Asked Questions
Can I use the RCP-1600-48 for 48V industrial networking or automation equipment?
Yes, this model provides 48V constant-voltage output at up to 1608W and 33.5A, which suits higher-power 48V DC industrial equipment. Its 90-264VAC input range also supports sites with different AC input standards.
Is the RCP-1600-48 a fit for centralized 48V embedded or communications power systems?
It can fit centralized 48V DC architectures where equipment is designed around a 48V bus and needs up to 33.5A. Programmable output voltage and current can also be useful in systems that require controlled 48V DC output behavior.
Can this unit be used in rack-mounted 48V power platforms that need redundancy or expansion?
Yes, the unit combines a 300.0 x 85.0 x 41.0 mm form factor with hot-swap support for serviceable rack power designs. Active current sharing up to 8000W also makes it suitable where multiple 48V supplies are combined for higher-capacity systems.
Is the RCP-1600-48 suitable for outdoor deployment or wide-temperature indoor use?
The operating temperature range is -30°C to +70°C, so it is specified for broad indoor temperature conditions. No IP rating is listed in the provided specs, so outdoor suitability is not confirmed by the product data shown here.
How does the RCP-1600-48 compare with the rest of the RCP series?
Among the listed 48V options, RCP-1000-48 is 1008W and 21A, RCP-1600-48 is 1608W and 33.5A, and RCP-2000-48 is 2016W and 42A. The listed 24V options are RCP-1000-24 at 960W and 40A, RCP-1600-24 at 1608W and 67A, and RCP-2000-24 at 1920W and 80A. The listed 12V options are RCP-1000-12 at 720W and 60A, RCP-1000-12-C at 1000W and 60A, RCP-1600-12 at 1500W and 125A, RCP-1UT at 3000W and 60A, and RCP-2000-12 at 1200W and 100A.
