Mean Well RPSG-160-15 Green Power Supply W 15V 7.3A - Medical Power...
Description
Description
Features
| 5"x3" compact size |
| 320W convection, 500W force air |
| 550W peak power (3 sec.)/td> |
| Medical safety approved (2xMOPP) according to ANSI/AAMI ES60601-1 and IEC/EN60601-1 |
| MEMI for both Class I & Class II configuration |
| -30~+70°C wide range operating temperature |
| No load power consumption under 0.5W by PS-ON control |
| High efficiency up to 94% |
| Protections: Short circuit / Overload / Over voltage / Over Temp. |
| 5Vdc standby output, 12Vdc fan supply, Power Good, Power Fail, and remote sense |
| Operating altitude up to 4000 meters (Note.5) |
| LED indicator for power on |
| 3 years warranty |
General Specification
| AC input voltage range | 80 ~ 264VAC | 113 ~ 370VDC |
| AC inrush current | COLD START 40A/115VAC 80A/230VAC |
| DC adjustment range | ±10% rated output voltage |
| Overload protection | 105%~135% hiccup mode, auto-recovery |
| Over-voltage protection | CH1: 115%~135% shut off, re-power on to recovery |
| Withstand voltage | I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC |
| Working temperature | -30~+70°C (refer to output derating curve) |
| Leakage current | Earth leakage current <220 A/264VAC 50Hz, Touch current < 100 A/264VAC |
| Safety standards | ANSI/AAMI ES60601-1, TUV EN60601-1 approved |
| EMC standards | EN55011/EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EN60601-1-2, EN61000-6-2 (RPS(G)-160) |
| Connection | 3+8+2(4)P/3.96mm pitch JST B3P / B8P-VH, B2B (B4B)-XH |
| Setup, rise, hold up time | 1000ms, 30ms, 10ms at full load and 230VAC |
| Dimension (LxWxH) | 127 x 76.2 x 41mm | 5 x 3 x 1.61 inch |
Specifications
Specifications
-
BrandMean Well
-
SeriesRPS Series
-
Power Rating112.5 Watt
-
Output Voltage15 Volt
-
Rated Current7.3 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,SHIDE
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length5 in
-
Width3 in
-
Height1.36 in
-
Weight0.71 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RPSG-160-15 for 15V industrial electronics or instrumentation?
Yes, for equipment that requires constant 15V DC and stays within 7.3A and 112.5W. It can fit industrial electronics, instrumentation, and embedded assemblies built around a 15V rail.
Is this a good fit for 15V medical devices or analyzer subsystems?
It can be used where a 15V constant voltage output is required and the load does not exceed 7.3A or 112.5W. Because it is listed as a medical power supply, it is relevant for medical or clinical equipment designs that need that supply class.
Can the RPSG-160-15 power a 15V automation or sensor-processing system?
It can fit 15V automation electronics, sensor-processing hardware, or control subsystems when their total demand remains at or below 7.3A and 112.5W. It is not the right choice for 12V, 24V, or 48V-only loads.
Can this power supply be used in hot or cold indoor equipment cabinets?
The specified operating range is -20°C to +70°C, so it supports a fairly wide indoor temperature window. Since no IP rating is listed, it should be installed in a protected enclosure and not in exposed outdoor or wet environments.
What are the differences between the RPSG-160-15 and the other RPSG-160 versions?
The series includes RPSG-160-5 at 103W and 5V 20A, RPSG-160-12 at 112.2W and 12V 9.1A, RPSG-160-15 at 112.5W and 15V 7.3A, RPSG-160-24 at 113.4W and 24V 4.6A, and RPSG-160-48 at 113.4W and 48V 2.3A. Selection within the family is mainly based on the required DC output voltage and current.
Other RPSG-160 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well RPSG-160-5 Green Power Supply W 5V 20A - Medical Power Supply | 103W | 5V | 20A | Indoor | $57.74 | View |
| Mean Well RPSG-160-48 Green Power Supply W 48V 2.3A - Medical Power Supply | 113.4W | 48V | 2.3A | Indoor | $57.74 | View |
| Mean Well RPSG-160-24 Green Power Supply W 24V 4.6A - Medical Power Supply | 113.4W | 24V | 4.6A | Indoor | $57.74 | View |
| Mean Well RPSG-160-12 Green Power Supply W 12V 9.1A - Medical Power Supply | 112.2W | 12V | 9.1A | Indoor | $57.74 | View |
