Description
Description
Features :
· 2:1 wide input range
· Protections: Short circuit / Overload / Over voltage / Over temperature
· 1500VAC I/O isolation
· Cooling by free air convection
· 100% full load burn-in test
· 24V and 48V input voltage design refer to LVD
· 2 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSD Series
-
Power Rating201.6 Watt
-
Output Voltage48 Volt
-
Rated Current4.2 Ampere
-
Input Voltage19V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetUL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty2 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.97 in
-
Weight2.43 lb
