Mean Well SD-200C-48 DC-DC Converter - 201.6W - 36~72V in 48V out 4.2A
1.0 (1 review)Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well SD-200C-48 DC-DC Converter - 201.6W - 36~72V in 48V out 4.2A
The SD-200C is a 200W Mean Well power converter (input range: 36~72VDC).
Key Features
- ✓ Input voltage range: 36~72VDC
- ✓ DC output voltage adjustable ±10%
- ✓ 1.5KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: IEC62368-1 CB
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSD Series
-
Power Rating201.6 Watt
-
Output Voltage24 Volt
-
Rated Current8.4 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetUL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty2 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.97 in
-
Weight2.43 lb
::specification::
Frequently Asked Questions
Can I use the SD-200C-48 to run a 24V industrial controller from a 36-72VAC DC bus system?
Yes, the listed specs show constant-voltage 24V output at up to 8.4A with a 36-72VAC input range. That makes it suitable when your source falls within 36-72VAC and the controller load stays within 201.6W.
Is this converter suitable for 24V automation sensors and I/O modules on mobile or embedded equipment?
It can fit 24V automation loads that need stable constant-voltage output rather than variable current drive. The rated output is 24V and 8.4A, so the combined load should remain within 201.6W.
Can the SD-200C-48 power a 24V HMI or communication panel in an industrial cabinet?
It is designed for constant-voltage output, so it can support 24V HMI or panel electronics when the total draw is within 8.4A. The 36-72VAC input range also gives flexibility for systems operating across that span.
Is the SD-200C-48 appropriate for indoor or outdoor environments?
The provided specs list an operating temperature of -20°C to +60°C, but no IP rating is stated. Without an IP rating, it should be treated as a converter for protected indoor enclosures rather than exposed outdoor use.
How does the SD-200C-48 compare with the other SD-200C models?
Within the SD-200C group, SD-200C-12 is listed at 200W, 5V, 40A; SD-200C-24 at 200.4W, 12V, 16.7A; SD-200C-48 at 201.6W, 24V, 8.4A; and SD-200C-5 at 201.6W, 48V, 4.2A. All are part of the same series family, but the output voltage, current, and wattage values differ by model.
