Mean Well SPB09C-05 DC-DC Converter - 9W - 36~75V in 5V out
Description
Description
Features
| SIP8 package with industry-standard pinout |
| 2:1 wide input range |
| Wide operating temperature range -40~+90°C |
| No minimum load required |
| High efficiency up to 89% |
| Protection: Short circuit(continuous)/Overload/Input under voltage |
| 1.5KVDC I/O isolation |
Remote ON/OFF control |
9V model available(optional) |
3 years warranty |
General Specification
| Voltage accuracy | ±1.5% |
| Vibration | 10 ~ 500Hz, 2G 10min./1 cycle, the period for 60min. each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | Continuous, auto-recovery |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.03% / ℃ (0 ~ 70℃) |
| Dimension (LxWxH) (mm) | 24*9.6*11.2mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPB Series
-
Power Rating9 Watt
-
Output Voltage5 Volt
-
Rated Current1.6 Ampere
-
Input Voltage36V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.98 in
-
Width0.44 in
-
Height0.38 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPB09C-05 to power a 5V industrial controller from a 36-75VAC source?
Yes, this model is a constant voltage DC-DC converter with a 36-75VAC input range and a 5V output. It is rated for 9W with up to 1.6A output current, so it fits 5V control electronics that stay within those limits.
Is this converter suitable for 5V embedded boards inside higher-voltage automation equipment?
It can fit embedded 5V loads when the available input is within 36-75VAC and the device needs constant 5V output. The 9W rating and 1.6A output current make it better suited to lower-power boards and interface electronics than larger 5V loads.
Can the SPB09C-05 be used for 5V sensors or industrial communication modules?
It is designed for constant 5V output, so it can be used for 5V sensors, signal modules, or communication electronics that operate from a 36-75VAC input source. The available output is limited to 9W and 1.6A, which is the sizing point to check against the connected load.
What is the difference between the SPB09C-05 and other SPB09C 9W models?
All SPB09C siblings in this group are rated at 9W, but the outputs differ: SPB09C-03 is 3.3V at 2A, SPB09C-05 is 5V at 1.6A, SPB09C-12 is 12V at 750A, SPB09C-15 is 15V at 600A, and SPB09C-24 is 24V at 375A. The shared format makes output voltage and current the main selection difference within the series.
Is the SPB09C-05 appropriate for outdoor or harsh-environment use?
The listed operating temperature range is -40°C to +90°C, which indicates broad thermal tolerance. No IP rating is provided in these specs, so outdoor exposure or washdown suitability is not established here and would need to be addressed at the enclosure level.
