Mean Well SPU03N-15 DC-DC Converter - 3W - 21.6~26.4V in 15V out
Description
Description
The SPU03N is a 3W Mean Well power converter (input range: 4.5~5.5V, operating temperature: -40~+90℃).
Key Features
- ✓ Input voltage range: 4.5~5.5V
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Overload
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSPU Series
-
Power Rating3 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty2 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.3 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPU03N-15 to derive 15V for low-power industrial control electronics from a 21.6~26.4V source?
Yes. This converter is specified for 21.6~26.4V input and provides a constant-voltage 15V output at 3W, which suits low-power industrial control and interface circuits that need a 15V rail. It is intended for small-load applications rather than higher-power 15V equipment.
Is the SPU03N-15 suitable for compact embedded systems that need 15V from a 24V-class input?
It is aligned with that use case because the listed input range is 21.6~26.4V and the output is 15V constant voltage. Its size is 19.6 x 10.2 x 7.5 mm, which helps in compact embedded assemblies. The 3W rating defines the supported load level.
Can this model be used in automation hardware installed in hot or cold operating areas?
The operating temperature range is -40°C to +90°C. That makes it suitable for automation hardware that must keep working across a broad ambient temperature range. CE and FCC certifications are also listed in the product data.
Is the SPU03N-15 intended for outdoor environments?
The provided specs do not show an IP rating. The temperature specification is -40°C to +90°C, but there is no stated water or dust protection level for outdoor exposure. Based on the listed information, ingress protection is unspecified.
How does the SPU03N-15 differ from the other models in the SPU03N range?
All listed SPU03N versions are 3W converters. The SPU03N-05 is shown as 3W, 12V, 250A; the SPU03N-12 is 3W, 15V, 200A; and the SPU03N-15 is 3W, 15V, 200A. The series entries also share 19.6 x 10.2 x 7.5 mm dimensions, a -40°C to +90°C operating range, and a 2-year warranty.
Other SPU03 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SPU03N-12 DC-DC Converter - 3W - 10.8~13.2V in 15V out | 3W | 15V | 0.2A | Indoor | $6.81 | View |
| Mean Well SPU03N-05 DC-DC Converter - 3W - 4.5~5.5V in 12V out | 3W | 12V | 0.25A | Indoor | $6.81 | View |
| Mean Well SPU03M-15 DC-DC Converter - 3W - 21.6~26.4V in 12V out | 3W | 12V | 0.25A | Indoor | $6.81 | View |
| Mean Well SPU03M-12 DC-DC Converter - 3W - 10.8~13.2V in 12V out | 3W | 12V | 0.25A | Indoor | $6.81 | View |
| Mean Well SPU03M-05 DC-DC Converter - 3W - 4.5~5.5V in 5V out | 3W | 5V | 0.6A | Indoor | $6.81 | View |
| Mean Well SPU03L-15 DC-DC Converter - 3W - 21.6~26.4V in 5V out | 3W | 5V | 0.6A | Indoor | $6.81 | View |
| Mean Well SPU03L-12 DC-DC Converter - 3W - 10.8~13.2V in 5V out | 3W | 5V | 0.6A | Indoor | $6.81 | View |
| Mean Well SPU03L-05 DC-DC Converter - 3W - 4.5~5.5V in 15V out | 3W | 15V | 0.2A | Indoor | $6.81 | View |
