Mean Well UHP-1000-36 Power Supply 1008W 36V
The UHP-1000 is a 1000W Mean Well power converter (input range: 12~14.4V).
Key Features
- ✓ Input voltage range: 12~14.4V
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesUHP Series
-
Power Rating1008 Watt
-
Output Voltage36 Volt
-
Rated Current28 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty5 Year
-
Length9.45 in
-
Width4.53 in
-
Height1.61 in
-
Weight3.84 lb
::specification::
Frequently Asked Questions
Can I use the UHP-1000-36 for a 36V industrial automation or motion-related DC load?
This model provides 36V constant-voltage output with 1008W total power and 28A output current. It fits 36V industrial or automation loads that need substantially more power than lower-wattage 36V supplies.
Is the UHP-1000-36 appropriate for a 36V embedded or control system with higher power demand?
It is intended for systems that require a stable 36V output and have load demand up to 1008W or 28A. The 90-264VAC input range also supports operation across a wide span of AC source conditions.
Can the UHP-1000-36 support a centralized 36V DC power supply design?
Yes, for designs built around a 36V constant-voltage bus, this supply offers 1008W of available output power. It is a practical choice when the total 36V load remains within 28A and 1008W.
What is the difference between the UHP-1000-36 and the other UHP-1000 models?
In the UHP-1000 family, the listed output variants are 12V 960W 80A, 24V 1008W 42A, 36V 1008W 28A, and 48V 1008W 21A. The shared specs shown here are 90-264VAC input, 240.0 x 115.0 x 41.0 mm dimensions, 1.74 kg weight, -30 C to +70 C operating temperature, CB/CE/EAC/TUV/UL certifications, a 5-year warranty, and a slim fanless low-profile design.
Is the UHP-1000-36 suitable for outdoor enclosures or only indoor use?
The unit is rated for operation from -30 C to +70 C, which covers a broad temperature range for equipment environments. No IP rating is listed in the provided specifications, so the data does not confirm outdoor or weather-exposed use.
