Mean Well UHP-200R-15 Power Supply 201W 15V - Redundant
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well UHP-200R-15 Power Supply 201W 15V - Redundant
The UHP-200R is a 200W Mean Well power converter (input range: 90~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ DC OK relay contact output
- ✓ Safety approvals: UL60950-1,TUV EN60950-1,EN60335-1, CCC GB4943, EAC TP TC 004, BSMI CNS14336-1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesUHP Series
-
Power Rating201 Watt
-
Output Voltage15 Volt
-
Rated Current13.4 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length7.64 in
-
Width2.17 in
-
Height1.02 in
-
Weight1.03 lb
::specification::
Frequently Asked Questions
Can I use the UHP-200R-15 for 15V industrial electronics or test equipment?
Yes, if the equipment requires a constant voltage 15V source and the load stays within 201W and 13.4A. This makes it a fit for 15V DC industrial electronics and bench or rack equipment built around that voltage.
Is the UHP-200R-15 appropriate for a monitored 15V control system?
Yes, the built-in DC OK and redundant function are the main reasons to choose this version for a monitored 15V system. It combines those features with a 15V, 201W, 13.4A output in a slim fanless package.
Can this 15V model be used in embedded or OEM equipment with limited space?
It can be a good fit where a 15V constant voltage supply is required and output demand remains within 13.4A. The 194.0 × 55.0 × 26.0 mm dimensions and fanless design support compact protected enclosures.
Would the UHP-200R-15 work for 15V instrumentation or panel subsystems that need redundancy features?
Yes, that is a reasonable use case if the subsystem runs on 15V DC and draws no more than 201W. The redundant function and DC OK feature distinguish it from a basic 15V supply when uptime monitoring is part of the requirement.
Is the UHP-200R-15 rated for outdoor conditions?
The specified operating temperature range is -30°C to +70°C. The provided specs do not state an IP rating, so outdoor, washdown, or direct-weather use is not defined by the listed data.
How does the UHP-200R-15 compare with the other UHP-200R redundant models?
The UHP-200R family includes 3.3V at 132W and 40A, 4.2V at 168W and 40A, 5V at 200W and 40A, 12V at 200.4W and 16.7A, 24V at 201.6W and 8.4A, 36V at 201.6W and 5.6A, and 48V at 201.6W and 4.2A. The UHP-200R-15 is the 15V version, rated 201W and 13.4A.
