Mean Well XLG-240-L-AB Power Supply 240W 700mA - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well XLG-240-L-AB Power Supply 240W 700mA - Adjustable and Dim...
The XLG-240-L is a 240W Mean Well DIN rail power converter with a 219mm profile (input range: 100~305VAC).
Key Features
- ✓ 219mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 100~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384; GB19510.1, GB19510.14;EAC TP TC 004; IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesXLG Series
-
Power Rating239.4 Watt
-
Output Voltage60 Volt
-
Rated Current0.7 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,RCM,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length8.62 in
-
Width2.48 in
-
Height1.4 in
-
Weight2.2 lb
::specification::
Frequently Asked Questions
Can I use the XLG-240-L-AB with a 0-10V dimming system for road or area lighting?
Yes. The AB suffix denotes a built-in dimming interface, allowing the driver to be controlled by standard 0-10V or PWM dimming signals. This makes the XLG-240-L-AB appropriate for smart street lighting networks or area light control systems.
Is the XLG-240-L-AB rated for use in outdoor wet locations?
Yes. The IP67 waterproof rating means the driver is protected against dust ingress and temporary immersion in water. It is suitable for exterior luminaires, street light poles, and other wet-location enclosures.
What LED string configurations does the XLG-240-L-AB support?
The driver operates in constant-current mode with a CC voltage range of 178–342V and 0.7A output current. It is designed for long series-connected LED module strings that operate at high forward voltages, typical in large outdoor luminaires, tunnel lights, and industrial high-bay fixtures.
Can the XLG-240-L-AB be installed in an enclosed outdoor fixture housing in cold climates?
Yes. With an operating temperature down to -40°C, the driver handles extreme cold. The metal case also conducts heat well in warmer ambient conditions. It can be fitted inside sealed IP-rated luminaire housings for outdoor use.
How does the XLG-240-L-AB compare to the XLG-240-L-A?
Both share the same 239.4W output, 178–342V CC voltage range, 0.7A current, and IP67 rating. The XLG-240-L-AB adds a dimming control input for external dimming signals; the XLG-240-L-A provides only manual current adjustment via potentiometer. Choose the AB when external dimming control is needed.
Will the XLG-240-L-AB operate on both 120V and 240V grid supplies?
Yes. The 100–305VAC input range covers standard residential, commercial, and industrial voltages worldwide, including 120V, 230V, and 277V supplies, without any manual switching.
