Mean Well LPC-35-700 Power Supply 35W 700mA
The LPC-35 is a 35W Mean Well DIN rail power converter with a 148mm profile (input range: 9~48V, operating temperature: -30~+70℃).
Key Features
- ✓ 148mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 9~48V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL1310, CAN/CSA C22.2 No. 223-M91(except for LPC-35-700), IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLPC Series
-
Power Rating33.6 Watt
-
Output Voltage48 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length5.83 in
-
Width1.57 in
-
Height1.18 in
-
Weight0.75 lb
::specification::
Frequently Asked Questions
Can I use the LPC-35-700 for a 700mA LED downlight?
Yes, this driver is designed for constant current LED loads at 700mA. It is a fit for LED downlights that need 700mA and operate within the 9-48V constant current range, with total load power up to 33.6W.
Is the LPC-35-700 suitable for LED signage modules?
It can be suitable for signage modules if the module string is a constant current 700mA load and falls within the 9-48V CC output range. With an IP67 enclosure and 33.6W output, it is better suited to sealed or exposed signage environments than a non-waterproof indoor-only driver.
Can the LPC-35-700 run a small LED array?
Yes, if the LED array is designed for constant current operation at 700mA. The array's total forward voltage must stay within 9-48V and the total power must remain within 33.6W.
Will the LPC-35-700 work with my LEDs if I do not know the LED count yet?
This depends on the LED string's total forward voltage, not a fixed LED count. The driver supplies 700mA constant current across 9-48V, so the number of LEDs will vary based on each LED's forward voltage; it is not intended for constant voltage LED loads.
Is the LPC-35-700 okay for outdoor or harsh environments?
It is rated IP67 and has an operating temperature range of -30°C to +70°C, so it is suitable for wet or dusty environments when the rest of the fixture is rated appropriately. Those specs make it more appropriate for exposed conditions than an indoor-only driver.
