Mean Well GSM06E05-P1J Power Supply 06W 5V
The GSM06E05 is a 6W Mean Well power converter.
Key Features
- ✓ Protections: Overload / Over voltage
- ✓ Safety approvals: ISOLATION LEVEL
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGSM Series
-
Power Rating6 Watt
-
Output Voltage5 Volt
-
Rated Current1.2 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~50°C
-
Warranty3 Year
-
Length2.6 in
-
Width1.67 in
-
Height1.26 in
-
Weight0.22 lb
::specification::
Frequently Asked Questions
What are the main output specifications of the Mean Well GSM06E05-P1J?
This model is a 6W AC/DC wall adaptor with a regulated 5V DC output and a rated current of 1.2A. It uses the P1J DC plug size of 2.1mm x 5.5mm x 11mm with center positive polarity. The unit is designed for universal input from 85 to 264VAC.
Is the GSM06E05-P1J suitable for medical equipment applications?
Yes. The GSM06E05-P1J is medical safety approved to EN60601-1 and EN60601-1-11, with 2 x MOPP isolation between primary and secondary. It also features low leakage current below 50uA, which is important for medical and patient-care environments.
What kind of plug and input type does this power supply use?
This version uses a 2-pole EURO wall plug and is a Class II power supply, so it does not require an earth pin. It is intended for regions and equipment setups that accept this plug style and 85 to 264VAC input. The compact wall-mount format makes it suitable where a separate desktop adaptor is not preferred.
What protection features are built into the GSM06E05-P1J?
The adaptor includes short circuit, overload, and over voltage protection. Overload protection operates in hiccup mode with auto-recovery, helping protect both the power supply and the connected load during fault conditions. It is also fully enclosed in a plastic case.
What operating environment is this adaptor rated for?
The GSM06E05-P1J is rated for operation from 0 to +50 degrees C, subject to the manufacturer's derating guidance. It also has no-load power consumption below 0.3W and efficiency up to 82%, which supports energy-conscious applications. For compliance-sensitive use, it meets listed EMC standards including EN60601-1-2.
Why would a buyer choose this model over a standard general-purpose 5V adaptor?
This model stands out because it combines a regulated 5V 1.2A output with medical approvals, 2 x MOPP isolation, and very low leakage current. It is a stronger fit when compliance, safety, and equipment-grade reliability matter more than using a basic consumer adaptor. The 3-year warranty also supports long-term B2B purchasing requirements.
