Mean Well GST18B07-P1J Power Supply 15W 7.5V
The GST18B07 is a 18W Mean Well power converter.
Key Features
- ✓ Protections: Overload / Over voltage
- ✓ Safety approvals: AS/NZS 60950.1 ,PSE J60950-1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGST Series
-
Power Rating15 Watt
-
Output Voltage7.5 Volt
-
Rated Current2 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CB,CCC,CE,EAC,FCC,KC,PSE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length3.11 in
-
Width2.13 in
-
Height1.3 in
-
Weight0.42 lb
::specification::
Frequently Asked Questions
Can I use the GST18B07-P1J for a 7.5V router, gateway, or network peripheral?
Yes, if the device is specified for 7.5V DC input and draws no more than 2A or 15W. This model provides constant-voltage 7.5V output, which suits electronics that require a fixed 7.5V rail. The 85-264VAC input range also supports use across varied AC mains conditions.
Is this 7.5V power supply suitable for small industrial control accessories?
It can work for low-power industrial accessories that call for 7.5V constant voltage and stay within 2A and 15W. That makes it more suitable for compact electronics and control accessories than for higher-power actuators or larger automation hardware. Buyers should confirm the accessory is actually rated for 7.5V input.
Can the GST18B07-P1J power a 7.5V test instrument or handheld dock?
Yes, it is appropriate for 7.5V equipment that needs a constant-voltage source up to 2A and 15W. This makes it a practical option for lighter-duty test or support equipment with a 7.5V requirement. Its small 79.0 × 54.0 × 33.0 mm housing also helps where space is limited.
Would this model fit a 7.5V embedded audio or communications device?
It can be a fit if the device requires regulated 7.5V DC and its total load does not exceed 2A or 15W. The unit is a constant-voltage supply, so it is intended for electronics with a defined 7.5V input requirement. It is not the right choice for products that need a different voltage rail.
Is the GST18B07-P1J meant for indoor or outdoor use?
The operating temperature range is -30°C to +70°C, which supports use in a wide range of protected environments. However, the provided specifications do not list an IP rating, so outdoor exposure or wet locations should not be assumed safe. It is best treated as a power supply for indoor or enclosure-protected applications.
