Mean Well DDR-60G-5 DC-DC Converter - 60W - 9~36V in 5V out 10.8A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well DDR-60G-5 DC-DC Converter - 60W - 9~36V in 5V out 10.8A
The DDR-60G is a 54W Mean Well DC-DC converter (input: 9~36VDC, operating temperature: -40~+85°C).
Key Features
- ✓ Input voltage: 9~36VDC
- ✓ Output voltage (max): 5V
- ✓ Rated output current: 10.8A
- ✓ I/O isolation: 500V
- ✓ Operating temperature: -40~+85°C
- ✓ Safety certifications: CE, EAC, EMC, UL
- ✓ 2 year warranty
-
BrandMean Well
-
SeriesDDR Series
-
Power Rating54 Watt
-
Output Voltage5 Volt
-
Rated Current10.8 Ampere
-
Input Voltage9V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty2 Year
-
Length3.54 in
-
Width2.15 in
-
Height2.07 in
-
Weight0.48 lb
::specification::
Frequently Asked Questions
Can I use the DDR-60G-5 to convert a 12V or 24V battery bank to 5V for embedded controllers in a DIN rail panel?
Yes. The DDR-60G-5 accepts 9-36V DC input, covering both 12V and 24V nominal battery systems. It outputs 5V at up to 10.8A (54W), which is sufficient for most embedded single-board computers, PLCs with 5V logic, or clusters of microcontroller boards mounted in a DIN rail enclosure.
Is the DDR-60G-5 suitable for powering USB charging hubs in industrial kiosks or HMI stations?
Yes. At 5V and 10.8A the DDR-60G-5 can supply up to 54W, enough to charge multiple USB devices simultaneously through a hub. Its DIN rail form factor and 4KVdc I/O isolation make it a good fit inside equipment cabinets where the source is a 12V or 24V DC bus.
Can the DDR-60G-5 power 5V LED indicator panels or small display modules in automation systems?
Yes. Many industrial LED indicator strips and small TFT displays run on 5V. The DDR-60G-5 provides 10.8A of current, so it can drive several indicator panels or HMI displays from a 9-36V DC bus without needing a separate AC-DC stage.
Will the DDR-60G-5 work in an unheated outdoor telecom cabinet during winter?
Yes. It is rated for an operating temperature range of -40°C to +85°C, so it will start and run reliably in extreme cold or hot environments. Its fanless design also means there are no moving parts that could fail in dusty or harsh conditions.
Can I mount the DDR-60G-5 inside a sealed control enclosure without forced-air cooling?
Yes. The DDR-60G-5 uses a fanless convection-cooled design, so it does not require ventilation fans. At 90.0 x 54.5 x 52.5 mm it is ultra-slim, which helps with heat dissipation in tight DIN rail enclosures. Ensure the enclosure ambient stays within the -40°C to +85°C operating range.
What other output voltages and wattages are available in the DDR-60G series?
The DDR-60G series includes four models: the DDR-60G-5 (54W, 5V, 10.8A), DDR-60G-12 (60W, 12V, 5A), DDR-60G-15 (60W, 15V, 4A), and DDR-60G-24 (60W, 24V, 2.5A). All share the same 9-36V input range, 90.0 x 54.5 x 52.5 mm DIN rail form factor, and fanless design with 4KVdc isolation.
