Mean Well DDR-60G-24 DC-DC Converter | 60W

Name: Mean Well DDR-60G-24 DC-DC Converter - 60W - 9~36V in 24V out 2.5A
Brand: Mean Well
SKU: DDR-60G-24
Price: 36.97 USD
Availability: InStock

Overview

DDR-60G-24 is the 24V output model of this series: rated current 2.5A, rated power 60W, typical efficiency 91%.

DDR-60 series is a 60W DIN Rail type DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (52.5mm), 4:1 ultra wide input voltage, -40~+85℃ wide operating temperature, 4KVdc I/O isolation, adjustable output voltage ( 10%) and full protective functions...etc. This series has two input options: 9~36V /18~75V and various output options: 5V / 12V / 15V / 24V and can be used for industrial control, security control, communication system and other fields. Suitable applications are DC buck/boost regulator, increasing system insulation level and voltage drop compensation along cable...etc.

Features

Width only 52.5mm (3SU)
4:1 ultra wide input range
-40~+85℃ wide working temperature
No minimum load required
DC output adjustable (±10%)
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection
4KVdc I/O isolation(Reinforced isolation)
3 years warranty

Specifications

DDR-60G-24Specifications from the official datasheet (2026-03-31 edition)

OUTPUT

DC VOLTAGE: 24V
RATED CURRENT: 2.5A
CURRENT RANGE: 0 ~ 2.5A
RATED POWER: 60W
RIPPLE & NOISE (max.)^Note.2: 100mVp-p
VOLTAGE ADJ. RANGE: 21.6 ~ 28V
VOLTAGE TOLERANCE^Note.3: ±2.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME: 120ms, 85ms at full load
HOLD UP TIME (Typ.): G-type: 5ms@24Vdc input
EXTERNAL CAPACITANCE LOAD (Max.): 2200μF

INPUT

VOLTAGE RANGE^Note.4: 9 ~ 36Vdc
EFFICIENCY (Typ.): 91%
DC CURRENT (Typ.): 3A /24Vdc
INRUSH CURRENT (Typ.): 20A /24Vdc

PROTECTION

OVERLOAD: 105 ~ 135% rated output power Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 28.8 ~ 34V Protection type : Shut down o/p voltage, re-power on to recover
REVERSE POLARITY: By internal MOSFET, no damage, recovers automatically after fault condition removed
UNDER VOLTAGE LOCKOUT: 24Vin (G-type):Power ON≥9V , OFF≤8.5V 48Vin (L-type):Power ON≥18V , OFF≤17V

ENVIRONMENT

WORKING TEMP.: -40 ~ +85℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 5 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +85℃, 5 ~ 95% RH non-condensing
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~60℃)
VIBRATION: Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6
OPERATING ALTITUDE: 5000 meters

SAFETY & EMC (Note 5)

SAFETY STANDARDS: IEC 62368-1, UL 62368-1, AS/NZS 62368-1, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:4KVdc
ISOLATION RESISTANCE: I/P-O/P>100M Ohms / 500Vdc / 25℃/ 70% RH
EMC EMISSION: Parameter Standard Test Level

Conducted BS EN/EN55032 Class A
Radiated BS EN/EN55032 Class A for 1m I/O cable , Class B for 30cm I/O cable
Voltage Flicker BS EN/EN61000-3-3 -----; BS EN/EN55035 , BS EN/EN61000-6-2(BS EN/EN50082-2)
EMC IMMUNITY: Parameter Standard Test Level

ESD BS EN/EN61000-4-2 Level 3, 8KV air; Level 3, 6KV contact; criteria A
Radiated BS EN/EN61000-4-3 Level 3, 10V/m; criteria A
EFT / Burst BS EN/EN61000-4-4 Level 3, 2KV; criteria A
Surge BS EN/EN61000-4-5 Level 3, 1KV/Line-Line; criteria A
Conducted BS EN/EN61000-4-6 Level 3, 10V; criteria A
Magnetic Field BS EN/EN61000-4-8 Level 4, 30A/m; criteria A

Parameter	Standard	Test Level
Conducted	BS EN/EN55032	Class A
Radiated	BS EN/EN55032	Class A for 1m I/O cable , Class B for 30cm I/O cable
Voltage Flicker	BS EN/EN61000-3-3	-----; BS EN/EN55035 , BS EN/EN61000-6-2(BS EN/EN50082-2)

Parameter	Standard	Test Level
ESD	BS EN/EN61000-4-2	Level 3, 8KV air; Level 3, 6KV contact; criteria A
Radiated	BS EN/EN61000-4-3	Level 3, 10V/m; criteria A
EFT / Burst	BS EN/EN61000-4-4	Level 3, 2KV; criteria A
Surge	BS EN/EN61000-4-5	Level 3, 1KV/Line-Line; criteria A
Conducted	BS EN/EN61000-4-6	Level 3, 10V; criteria A
Magnetic Field	BS EN/EN61000-4-8	Level 4, 30A/m; criteria A

OTHERS

MTBF: 3261.6K hrs min. Telcordia SR-332 (Bellcore) ; 611.1K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 52.5*90*54.5mm (W*H*D)
PACKING: 216g; 60pcs/14Kg/0.97CUFT

Test conditions and notes6

1. All parameters NOT specially mentioned are measured at normal input (G:24Vdc, L:48Vdc), rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltage. Please check the derating curve for more details.
5. The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
6. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

DDR-60G-24 Block Diagram — Block Diagram

DDR-60G-24 Derating Curve — Derating Curve

DDR-60G-24 Output derating VS input voltage — Output derating VS input voltage

DDR-60G-24 Mechanical Specification — Mechanical Specification

Typical applications

Downloads

Certificates4

CE Certificate(DDR-60)(EN) PDF Download

UL Certificate(DDR-60)(EN) PDF Download

EMC Certificate(DDR-60)(EN) PDF Download

EAC Certificate(EN) PDF Download

Catalogues2

Mean Well DC-DC Catalog PDF Download

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the DDR-60G-24 to step up a 12V battery system to 24V for industrial sensors?

Yes. The DDR-60G-24 accepts 9-36V DC input, so it can produce a regulated 24V output at up to 2.5A (60W) from a 12V battery source; the datasheet notes derating may be needed at low input voltage. This is useful for powering 24V industrial sensors, small PLCs, and communication modules from a 12V battery bank in remote or mobile installations.

Is the DDR-60G-24 suitable for converting a 24V solar charge controller output to a clean 24V rail?

The DDR-60G-24 accepts 9-36V and outputs a regulated 24V at 2.5A. Even though the input and output are both nominally 24V, the converter provides isolation and regulation that protects sensitive 24V loads from voltage fluctuations on the solar bus. The 4KVdc isolation is particularly valuable for separating solar and load ground references.

Can the DDR-60G-24 power a 24V DIN rail gateway or edge computing device in a small control panel?

Yes. At 60W and 24V/2.5A, the DDR-60G-24 can power compact IoT gateways, edge controllers, and protocol converters. Its small 52.5 x 90 x 54.5 mm size and 216g weight fit easily in space-constrained panels.

Can I install the DDR-60G-24 in a freezer room or cold storage facility?

The DDR-60G-24 is rated for operation from -40 to +85 degrees Celsius, so it handles cold storage and freezer environments without any issues. It should still be protected from direct contact with water or ice, as it does not carry an IP ingress protection rating.

How does the 60W DDR-60G-24 compare to higher-wattage 24V options in the DDR series?

This datasheet covers only the 60W DDR-60 models. For 24V output there are two: the DDR-60G-24 (9-36V input) and the DDR-60L-24 (18-75V input), both 60W at 2.5A. If your load needs more than 60W, you will need a model from a different, higher-power series.
