Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well DDR-60L-5 DC-DC Converter - 60W - 18~75V in 5V out
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well DDR-60L-5 DC-DC Converter - 60W - 18~75V in 5V out
The DDR-60L is a 60W DIN Rail type DC-DC converter with a 52.5mm (3SU) profile, designed for systems fed from 24V or 48V DC sources. A 4:1 wide input voltage range of 18~75Vdc covers both nominal 24V and 48V DC bus supplies, while reinforced 4KVdc I/O isolation ensures noise-free power delivery. Free air convection cooling and no minimum load requirement make it simple to deploy across a -40~+85°C operating range.
Key Features
- ✓ Compact 52.5mm (3SU) width — DIN rail TS-35/7.5 or 15 compatible
- ✓ 4:1 wide input voltage range: 18~75Vdc
- ✓ DC output voltage adjustable ±10%
- ✓ 4KVdc reinforced I/O isolation
- ✓ Cooling by free air convection — no minimum load required
- ✓ Wide operating temperature: -40°C ~ +85°C
- ✓ Protections: Short circuit / Overload / Over voltage / Reverse polarity / Under voltage lockout
- ✓ Safety approvals: UL 62368-1, IEC 62368-1, AS/NZS 62368.1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDDR Series
-
Power Rating60 Watt
-
Output Voltage5 Volt
-
Rated Current12 Ampere
-
Input Voltage18V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty2 Year
-
Length3.54 in
-
Width2.15 in
-
Height2.07 in
-
Weight0.48 lb
::specification::
Frequently Asked Questions
Can I use the DDR-60L-5 to power 5V embedded systems from a 48V DC distribution bus in an industrial panel?
Yes. The DDR-60L-5 accepts 18-75V DC, covering standard 48V bus voltages. It outputs 5V at up to 12A (60W), which is sufficient for multiple single-board computers, Raspberry Pi clusters, or 5V microcontroller boards mounted in a DIN rail enclosure.
Is the DDR-60L-5 a good option for providing 5V to USB-powered diagnostic tools in a 48V-powered mobile service vehicle?
Yes. The 18-75V input range accommodates 48V vehicle electrical systems including voltage fluctuations during engine cranking or charging. At 12A on the 5V output, it can supply USB diagnostic tablets, handheld scanners, or test equipment through appropriate USB power distribution boards.
Can the DDR-60L-5 power 5V digital signage controllers or media players in a commercial installation?
Yes. Many compact media players and signage controllers require 5V at 2-3A. The DDR-60L-5 provides 12A total, so it can power multiple such devices from a single converter. The 4KVdc I/O isolation protects sensitive digital equipment from noise on the upstream 48V or 24V DC line.
How does the DDR-60L-5 differ from the DDR-60G-5 if I need a 5V DC-DC converter?
Both are DIN rail 5V converters in the same 90.0 x 54.5 x 52.5 mm form factor. The DDR-60G-5 accepts 9-36V DC input (suited for 12V or 24V sources) and delivers 54W at 10.8A. The DDR-60L-5 accepts 18-75V DC input (suited for 24V or 48V sources) and delivers 60W at 12A. Choose based on your upstream DC bus voltage.
Will the DDR-60L-5 operate reliably in an outdoor traffic control cabinet with no active cooling?
Yes. It is rated from -40°C to +85°C and uses a fully fanless convection-cooled design, so it needs no ventilation. Traffic control cabinets in extreme climates are well within its operating envelope as long as internal ambient temperature stays below +85°C.
Can I install the DDR-60L-5 in a sealed enclosure in a cold-storage warehouse at sub-zero temperatures?
Yes. The DDR-60L-5 is rated to start and operate at temperatures as low as -40°C. Cold-storage environments typically range from -25°C to -18°C, which is well within its specification. The fanless design avoids ice accumulation on moving parts.
