Mean Well DDR-60L-15 DC-DC Converter - 60W - 18~75V in 15V out

2:1 or 4:1 wide input range, fanless design, 4KVdc I/O isolation, ultra slim dimensions
$32.54 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

Features

Width only 52.5mm (3SU)
DC output adjustable ( 10%)
4:1 ultra wide input range
No minimum load required
Protections: Short circuit / Overload / Over voltage /Input reverse polarity / Input under voltage protection
4KVdc I/O isolation(Reinforced isolation)
Can be installed on DIN rail TS-35/7.5 or 15
-40~+85°C wide working temperature
Cooling by free air convection
3 years warranty

General Specification

Over current protection 110%~150% rated output power;Protection type:Constant current limiting, recovers automatically after fault condition is removed
Over voltage protection

5V:5.75~7V ; 12V:13.8~16.2V ; 15V:17.25~20.25V ; 24V:28.8~32.4V;

Protection mode:Shut down o/p voltage, re-power on to recover

REVERSE POLARITY By internal MOSFET, no damage, recovers automatically after fault condition removed
Withstand voltage I/P-O/P:4KVDC
Working temperature -40~+85°C (Refer to ""Derating Curve"")
Safety standards IEC 62368-1 (LVD) approved, Design refer to UL508
EMC standards With external components Compliance to EN55032 Class A for 1m I/O cable,Class B for 30cm I/O cable ;EN61000-3-,3,EN61000-4-2,3,4,5,6,8
Dimension (LxWxH)(mm) 52.5 x 90 x 54.5 mm

Specifications

  • Brand
    Mean Well
  • Series
    DDR Series
  • Power Rating
    60 Watt
  • Output Voltage
    15 Volt
  • Rated Current
    4 Ampere
  • Input Voltage
    18V~75V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CE,EAC,EMC,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~85°C
  • Warranty
    2 Year
  • Length
    3.54 in
  • Width
    2.15 in
  • Height
    2.07 in
  • Weight
    0.48 lb
