Mean Well HBG-100-60DA Power Supply 100W 60V - DALI
The HBG-100 is a 100W Mean Well power converter (input range: 14.4~24V).
Key Features
- ✓ Input voltage range: 14.4~24V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating96 Watt
-
Output Voltage62 Volt
-
Rated Current1.6 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.12 in
-
Width5.12 in
-
Height2.62 in
-
Weight2.6 lb
::specification::
Frequently Asked Questions
Can I use the Mean Well HBG-100-60DA for a constant-current LED array in a high or low bay fixture?
Yes, this LED driver is intended for high and low bay lighting and provides constant current output across a 36-60V range. It is a fit when the LED array is a constant-current load that stays within the 96W rating, and the DA version is appropriate when DALI control is required.
Can I use this driver for LED downlights?
It can work for LED downlights only when the fixture uses a constant current driver and the LED load operates within the 36-60V constant current range. It is not the right choice for downlights that require a constant voltage power supply instead of constant current.
Can I use the HBG-100-60DA for LED signage modules?
Only if the signage assembly is designed as a constant current load within the 36-60V output range and within the 96W power rating. Many signage modules use constant voltage power supplies, so this model is not a match for constant voltage signage products.
Is this LED driver suitable for a small LED array?
Yes, if the small LED array is a constant current load and its operating voltage falls within 36-60V. The number of LEDs depends on each LED's forward voltage, so compatibility should be checked against the full array voltage rather than a fixed LED count.
How do I know if my LED load is compatible with the HBG-100-60DA?
The LED load must be designed for constant current operation, and its operating range must fit within the driver's 36-60V constant current output range. The number of LEDs that can be driven depends on the forward voltage of each LED, so there is no single fixed LED count for this model.
Can the HBG-100-60DA be used outdoors or in harsh environments?
This model has an IP67 waterproof rating and operates from -40°C to +85°C, which makes it suitable for demanding indoor or outdoor environments when the rest of the fixture is designed for those conditions. Its metal case and 5-year warranty also align with tougher commercial lighting applications.
What is the difference between the HBG-100-60DA and other HBG-100 60V models?
Within the HBG-100 60V group, the HBG-100-60, HBG-100-60A, HBG-100-60AB, HBG-100-60B, HBG-100-60DA, and HBG-100-60E all share a 36-60V constant current range and 96W class output. The HBG-100-60DA is the DALI version in that sibling set, while the other suffix variants are separate series options under the same 60V and 96W family.
