Mean Well HVG-240-36AB Power Supply 240W 36V - Adjustable and Dimmable

Name: Mean Well HVG-240-36AB Power Supply 240W 36V - Adjustable and Dimmable
Brand: Mean Well
SKU: HVG-240-36AB
Price: 96.07 USD
Availability: InStock

wide input range 180~528VACaluminium casing

SKU:

HVG-240-36AB

$96.07 USD ~~$347.25~~

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The HVG-240 is a 240W Mean Well power converter (input range: 180~528VAC).

Key Features

✓ Input voltage range: 180~528VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL8750 (type”HL”), CSA C22.2 No. 250.13-12, EAC TP TC 004 IP65 or IP67
✓ 3 years warranty

Brand

Mean Well
Series

HVG Series
Power Rating

241.2 Watt
Output Voltage

36 Volt
Rated Current

6.7 Ampere
Input Voltage

180V~528V
No of Output

1
Dimming Control

10V PWM,1-10V,Built-in Potentiometer,Resistance
Standards Met

EAC,FCC,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

5 Year
Length

10.01 in
Width

2.68 in
Height

1.53 in
Weight

2.89 lb

Frequently Asked Questions

Can I use the HVG-240-36AB for 36V dimmable LED lighting?

Yes, this model is the 36V, 241.2W, 6.7A adjustable and dimmable option in the series. It fits 36V constant current lighting loads within the 18-36V CC range when the total demand stays at or below 241.2W.

Is the HVG-240-36AB a good fit for 36V sign lighting that needs output adjustment?

It is intended for 36V constant current LED lighting loads, so it can fit sign-lighting products that match the 36V output, 6.7A current, and 241.2W maximum power. The adjustable design is relevant when the lighting product's electrical requirements fall within the listed 18-36V constant current range.

Can this model be used for 36V canopy or area lighting in damp locations?

The IP65 water-resistant enclosure supports use in damp or outdoor locations, provided the lighting load is also suitable for that environment. Electrically, the load still needs to match 36V constant current operation and remain within 241.2W and 6.7A.

Can the HVG-240-36AB power a long 36V LED strip run?

For wattage planning, use the 241.2W maximum output and divide it by the strip's rated watts per meter. For example, the formula is 241.2W ÷ strip W/m, but you should check your strip rated power per meter and verify that the strip is compatible with 36V constant current output.

Is IP65 enough for outdoor lighting projects?

IP65 means the driver is water-resistant and suited to outdoor or wet-area exposure where direct weather resistance is needed. It is not the same as the IP67 waterproof rating used on the HVG-240-36B, so the environment should be matched to the enclosure rating.

What is the difference between HVG-240-36A, 36AB, 36B, and the other HVG-240 voltages?

Within the 36V versions, HVG-240-36A, HVG-240-36AB, and HVG-240-36B are all listed at 241.2W, 36V, and 6.7A, while HVG-240-36D2 is listed at 240W. Across the HVG-240 family, the other outputs are 24V at 240W and 10A, 30V at 240W and 8A, 42V at 239.4W and 5.7A, 48V at 240W and 5A, and 54V at 243W and 4.5A.
