Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well HVG-240-54AB Power Supply 240W 54V - Adjustable and Dimmable

Name: Mean Well HVG-240-54AB Power Supply 240W 54V - Adjustable and Dimmable
Brand: Mean Well
SKU: HVG-240-54AB
Price: 85.59 USD
Availability: InStock

wide input range 180~528VACaluminium casing

SKU:

HVG-240-54AB

$85.59 USD ~~$347.25~~

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The HVG-240 is a 240W Mean Well power converter (input range: 180~528VAC).

Key Features

✓ Input voltage range: 180~528VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL8750 (type”HL”), CSA C22.2 No. 250.13-12, EAC TP TC 004 IP65 or IP67
✓ 3 years warranty

Brand

Mean Well
Series

HVG Series
Power Rating

243 Watt
Output Voltage

54 Volt
Rated Current

4.5 Ampere
Input Voltage

180V~528V
No of Output

1
Dimming Control

10V PWM,1-10V,Built-in Potentiometer,Resistance
Standards Met

EAC,FCC,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

5 Year
Length

10.01 in
Width

2.68 in
Height

1.53 in
Weight

2.89 lb

Frequently Asked Questions

Can I use the HVG-240-54AB for a 54V LED strip lighting run?

Yes, if the strip or lighting load is designed for 54V and stays within the driver's 243W maximum output. This model delivers up to 4.5A with a constant current range of 27-54V, so the load needs to fit within those limits.

Is this driver suitable for 54V illuminated signage or channel letter lighting?

It can be used for 54V signage lighting loads that need up to 243W total and up to 4.5A output current. The IP65 water-resistant housing also makes it suitable for signage locations where rain or washdown exposure is possible.

Can the HVG-240-54AB power outdoor architectural lighting?

Yes, for 54V architectural lighting loads that fit within the 27-54V constant current range and 243W maximum power. Its IP65 rating and -40°C to +90°C operating temperature range make it appropriate for demanding outdoor environments.

Can I use this for a high-power 54V commercial lighting fixture?

Yes, if the fixture is a 54V load and does not exceed 243W or 4.5A. This driver is intended for constant current operation, so the fixture's electrical requirements need to match the 27-54V CC range.

How much 54V LED strip can this driver support?

Use the driver power rating to estimate strip length: maximum length = 243W divided by your strip's watts per meter. For example, the math is 243W / strip W per meter = maximum meters, but you should check your strip rated power per meter before sizing.

Is the HVG-240-54AB okay for wet or outdoor locations?

Yes, it has an IP65 water-resistant rating, so it is suitable for outdoor and wet-area use where water spray or rain is expected. It is also rated for -40°C to +90°C operation, which helps in hot and cold conditions.

How does the HVG-240-54AB compare with the other 54V models in the 240W HVG group?

In the 240W 54V group, HVG-240-54A, HVG-240-54AB, and HVG-240-54B are all rated at 243W, 54V, and 4.5A. The HVG-240-54D2 is listed at 240W.
