Mean Well HEP-150-48A Power Supply 153.6W 48V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-150-48A Power Supply 153.6W 48V
The HEP-150 is a 150W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC, operating temperature: -60~+80°C).
Key Features
- ✓ 228mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -60~+80°C
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-150 Blank type), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating153.6 Watt
-
Output Voltage48 Volt
-
Rated Current3.2 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can the HEP-150-48A be used for 48V building automation or access-control hardware?
Yes, if the hardware requires a constant-voltage 48V DC source. The unit can provide up to 3.2A and 153.6W, so the full system load needs to stay within that capacity.
Is this model suitable for 48V industrial communications or control panels?
It is a fit for 48V communications or control equipment that is designed for constant-voltage input. The broad 90-305VAC input range is useful where AC supply conditions vary from site to site.
Can I use the HEP-150-48A for a rugged 48V embedded system?
It can be used with embedded systems that call for 48V constant voltage and stay at or below 153.6W. The fanless design, rugged metal case, and 10G vibration specification support use in harsh environments.
Is the HEP-150-48A intended for indoor or outdoor environments?
With an IP65 Water-Resistant rating, this version is suitable for dusty areas and for locations exposed to water spray or rain. Its operating temperature range is -55°C to +70°C, but it is not the IP68 version of the 48V model.
What are the HEP-150-48A alternatives in the same HEP-150 family?
The HEP-150 range includes HEP-150-12 and HEP-150-12A at 150W, 12V, 12.5A; HEP-150-15 and HEP-150-15A at 150W, 15V, 10A; HEP-150-24 and HEP-150-24A at 151.2W, 24V, 6.3A; HEP-150-36 and HEP-150-36A at 151.2W, 36V, 4.2A; HEP-150-48 and HEP-150-48A at 153.6W, 48V, 3.2A; and HEP-150-54 and HEP-150-54A at 151.2W, 54V, 2.8A. The HEP-150-48A matches HEP-150-48 electrically at 48V, 3.2A, and 153.6W.
