Mean Well MHB75-48S05 DC-DC Converter - 75W - 36~72V in 5V out
The MHB75 is a 75W Mean Well power converter (input range: 9~18VDC).
Key Features
- ✓ Input voltage range: 9~18VDC
- ✓ Protections: Short circuit / Over voltage / Over temperature / Under voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL60950-1 EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesMHB Series
-
Power Rating75 Watt
-
Output Voltage5 Volt
-
Rated Current15 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,EMC,RCM,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~105°C
-
Warranty3 Year
-
Length2.4 in
-
Width2.28 in
-
Height0.5 in
-
Weight0.2 lb
::specification::
Frequently Asked Questions
Can I use the MHB75-48S05 for 5V embedded or industrial electronics on higher-voltage systems?
Yes, this model is designed for a 36-72VAC input range and provides a 5V constant-voltage output. With up to 15A and 75W available, it suits 5V embedded or industrial electronics that need higher current from a higher-voltage source range.
Is the MHB75-48S05 suitable for 5V control or communications hardware in industrial equipment?
It is a fit for 5V constant-voltage hardware that stays within the 15A and 75W limits. In industrial equipment where the available input falls in the 36-72VAC range, this model matches 5V control or communications loads better than the 12V or 24V output versions.
Can this converter be used where space is limited but current demand is high at 5V?
The unit is compact at 61.0 × 57.9 × 12.7 mm and weighs 0.092 kg, while still providing 5V at up to 15A. That combination is useful for dense assemblies that need more current on a 5V rail without moving to a larger 75W class product.
Is the MHB75-48S05 appropriate for harsh temperature environments or outdoor use?
Its operating temperature range is -55°C to +105°C, so it is specified for extreme temperature conditions. The provided specs do not include an IP rating, so suitability for outdoor exposure, water, or dust cannot be determined from this information alone.
How does the MHB75-48S05 compare with the other high-input MHB75 models?
Within the 36-72VAC input group, the available outputs are 5V at 15A for MHB75-48S05, 12V at 6.25A for MHB75-48S12, and 24V at 3.13A for MHB75-48S24. All are rated at 75W and share the same 61.0 × 57.9 × 12.7 mm dimensions, 0.092 kg weight, and -55°C to +105°C operating range.
