Mean Well ENP-360-24 Desktop Type Chargers 360W 27.6V 13A - Level VI Power Supply
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ENP-360-24 Desktop Type Chargers 360W 27.6V 13A - Level V...
EN55032 Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11
Key Features
- ✓✓Universal AC input/Full range
- ✓✓Built-in active PFC function
- ✓✓Energy efficiency Level VI
- ✓✓No load power consumption <0.5W
- ✓✓Comply with EISA 2007/DoE, NRCan, and EU Erp
- ✓✓125% peak load capability
- ✓✓Fanless design, cooling by free air convection
- ✓✓Protection: Short circuit/ Overload/ Over voltage/ Over temperature
- ✓✓3 years warranty
-
BrandMean Well
-
SeriesENP Series
-
Power Rating360 Watt
-
Output Voltage27.6 Volt
-
Rated Current13 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length7.56 in
-
Width7.01 in
-
Height1.79 in
-
Weight3.31 lb
::specification::
Frequently Asked Questions
What is the output of the Mean Well ENP-360-24?
The ENP-360-24 is rated for 360W output at 27.6V DC and 13A. This makes it suitable for applications that need a higher-power 24V-class desktop power supply or charger with consistent output performance.
Is the ENP-360-24 designed as a battery charger or a power supply?
This model is marketed as a desktop type charger and power supply, so buyers commonly consider it for both roles depending on their equipment requirements. The listed output is 27.6V, which is often relevant where a 24V nominal system requires a higher charging or operating voltage.
What protections are included in the ENP-360-24?
The ENP-360-24 includes protection for short circuit, overload, over voltage, and over temperature. It also supports peak loading up to 125% of rated output power for more than 3 seconds before switching to constant current limiting with auto-recovery after the condition is removed.
Can the ENP-360-24 be used in demanding temperature environments?
This model has a specified working temperature range of -30°C to +70°C. That wide range makes it a practical option for commercial and industrial environments where ambient conditions may be more demanding than standard indoor use.
How energy efficient is the Mean Well ENP-360-24?
The ENP-360-24 meets Energy Efficiency Level VI and has no-load power consumption below 0.5W. It is also listed as complying with EISA 2007/DoE, NRCan, and EU ErP requirements, which is relevant for buyers evaluating operating efficiency and regulatory alignment.
What input range and compliance standards does the ENP-360-24 support?
The unit accepts a universal AC input range of 90 to 264VAC and also supports 127 to 370VDC input. It is approved to IEC62368-1 and UL62368-1 standards and meets EN62368-1 and EN55032 Class B EMC-related requirements as listed in the product specification.
