Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well ENP-360-12 Desktop Type Chargers 360W 13.8V 26A - Level VI Power Supply
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ENP-360-12 Desktop Type Chargers 360W 13.8V 26A - Level V...
Description
Description
Features
| Universal AC input/Full range |
| Built-in active PFC function |
| Energy efficiency Level VI |
| No load power consumption <0.5W |
| Comply with EISA 2007/DoE, NRCan, and EU Erp |
| 125% peak load capability |
| Fanless design, cooling by free air convection |
| Protection: Short circuit/ Overload/ Over voltage/ Over temperature |
| 3 years warranty |
General Specification
| AC input voltage range | 90~264VAC 127~370VDC |
| AC inrush current (max.) | Cold start, 60A at 230VAC |
| Overload protection | Normally works within 110 ~ 125% rated output power for more than 3 seconds and switches to constant current limiting, with auto-recovery after the peak load condition is removed |
| Over-voltage protection | 112%~131% rated voltage |
| Setup, rise, hold up time | 1000ms,100ms,20ms at full load |
| Withstand voltage | I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
| Working temperature | -30~+70ºC |
| Safety standards | IEC62368-1, UL62368-1 EAC TP TC 004, J62368-1(2020)(Only for 12V) approved; Meet EN62368-1 |
| EMC standards | EN55032 Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11 |
| Dimension (LxWxH) (mm) | 192x178x45.5mm |
| Packing | 10pcs/16Kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesENP Series
-
Power Rating360 Watt
-
Output Voltage13.8 Volt
-
Rated Current26 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length7.56 in
-
Width7.01 in
-
Height1.79 in
-
Weight3.31 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What output does the Mean Well ENP-360-12 provide?
The ENP-360-12 is a 360W desktop power supply with a 13.8V DC output and 26A rated current. This makes it suitable for applications that need a regulated 13.8V supply at relatively high current from a compact external unit.
Is the ENP-360-12 designed for energy-efficient operation?
Yes. This model is rated to Energy Efficiency Level VI and has no-load power consumption below 0.5W. It also complies with EISA 2007/DoE, NRCan, and EU ErP efficiency requirements listed in the product data.
Can the ENP-360-12 handle temporary peak demand above its rated output?
Yes. Mean Well specifies 125% peak load capability, and the overload protection section states it can normally operate at 110% to 125% of rated output power for more than 3 seconds. After that, it switches to constant-current limiting and auto-recovers once the overload condition is removed.
Is this model fanless?
Yes. The ENP-360-12 uses a fanless design with cooling by free air convection. That can be useful in environments where lower noise, reduced dust intake, or less mechanical wear is preferred.
What operating temperature range is supported?
The specified working temperature range is -30°C to +70°C. Buyers should still confirm that the surrounding enclosure and overall system conditions stay within the product's published operating limits.
What protection and compliance features are included on the ENP-360-12?
This model includes short circuit, overload, over-voltage, and over-temperature protection. It is also listed with IEC62368-1, UL62368-1, J62368-1(2020) approval for the 12V version, and EMC compliance including EN55032 Class B and related EN61000 standards.
