Mean Well ENP-360-48 Desktop Type Chargers 360W 55.2V 6.5A - Level VI Power Supply

The ENP-360-48 is a 360W desktop power supply with a rated output of 55.2V DC and 6.5A. It is designed for applications that require this specific voltage and current combination. This model also supports up to 125% peak load capability for short-duration demand.

Yes. This model supports a universal AC input range of 90 to 264VAC, as well as 127 to 370VDC input. That makes it suitable for use in regions with different mains voltage standards.

The ENP-360-48 uses a fanless design and cools by free air convection. That can be useful in environments where lower acoustic noise and reduced moving-part maintenance are preferred. Its specified working temperature range is -30°C to +70°C.

This model includes protection for short circuit, overload, over-voltage, and over-temperature conditions. Its overload behavior is specified to operate within 110% to 125% of rated output power for more than 3 seconds before switching to constant current limiting. It then auto-recovers after the peak load condition is removed.

The ENP-360-48 is rated to Energy Efficiency Level VI. It also has no-load power consumption below 0.5W and is stated to comply with EISA 2007/DoE, NRCan, and EU ErP requirements. These features make it a stronger fit for energy-conscious commercial applications.

This model is generally suited for equipment that needs a regulated 55.2V DC output at up to 6.5A in a desktop form factor. Buyers often consider it where high efficiency, active PFC, and fanless operation are important. The exact application should match the equipment's required voltage and current specifications.

The unit measures 192 x 178 x 45.5 mm and has a listed weight of 1.5 kg. It is supplied with a 3-year warranty from Mean Well. Those details can help when comparing enclosure space, portability, and support coverage.
