Mean Well EPP-100-27 Power Supply 75W 27V
<2mA/264VAC
Key Features
- ✓✓4"x2" compact size
- ✓✓Universal AC input / Full range
- ✓✓Built-in active PFC function
- ✓✓High efficiency up to 92.5%
- ✓✓Protections: Short circuit/Overload/Over voltage/Over temperature
- ✓✓75W free air convection, 100W with 20CFM forced air
- ✓✓LED indicator for power on
- ✓✓No-load power consumption<0.5W
- ✓✓Built-in 12V/0.3A auxiliary output
- ✓✓3 years warranty
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating75.6 Watt
-
Output Voltage27 Volt
-
Rated Current2.8 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length4 in
-
Width2 in
-
Height1.14 in
-
Weight0.44 lb
::specification::
Frequently Asked Questions
Can I use the EPP-100-27 for 27V industrial control or test equipment?
Yes, this model is a constant-voltage 27V supply rated for 2.8A and 75.6W. It fits industrial or embedded equipment that specifically requires 27V DC and stays within that 2.8A and 75.6W output limit.
Is the EPP-100-27 suitable for a 27V automation panel subsystem?
It can be used for a 27V automation subsystem when the connected load needs constant-voltage 27V power and draws no more than 2.8A. The wide 90-264VAC input also helps when the equipment is deployed across facilities with different AC supply standards.
Can this 27V power supply run embedded electronics that need stable DC output?
Yes, the EPP-100-27 is designed for constant-voltage output at 27V with up to 75.6W available. That makes it appropriate for embedded electronics, instruments, or control assemblies that are designed for 27V DC and need 2.8A or less.
Is the EPP-100-27 meant for outdoor or exposed environments?
This unit has an operating temperature range of -30°C to +70°C, but no IP rating is listed in the specs. That points to use inside protected equipment or an enclosure rather than direct outdoor or washdown exposure.
How does the EPP-100-27 compare with the other 27V models in the EPP series?
Within the 27V group, the EPP-100-27 is rated at 75.6W and 2.8A, the EPP-120S-27 is 119.9W and 4.44A, the EPP-150-27 is 100.17W and 3.71A, the EPP-200-27 is 143.1W and 5.3A, the EPP-300-27 is 199.8W and 7.4A, the EPP-400-27 is 251.1W and 9.3A, and the EPP-500-27 is 321.3W and 11.9A. The main differences are output power and available current at the same 27V output.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other EPP-100 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well EPP-100-48 Power Supply 76W 48V | 76.8W | 48V | 1.6A | Indoor | $41.23 | View |
| Mean Well EPP-100-24 Power Supply 76W 24V | 76.8W | 24V | 3.2A | Indoor | $41.12 | View |
| Mean Well EPP-100-15 Power Supply 75W 15V | 75W | 15V | 5A | Indoor | $41.23 | View |
| Mean Well EPP-100-12 Power Supply 75W 12V | 75.6W | 12V | 6.3A | Indoor | $41.23 | View |
