Mean Well NPF-60D-24 Power Supply 60W 24V - Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NPF-60D-24 Power Supply 60W 24V - Dimmable
The NPF-60D is a 60W Mean Well DIN rail power converter with a 150mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 150mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750(type”HL”), CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating60 Watt
-
Output Voltage24 Volt
-
Rated Current2.5 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.91 in
-
Width2.09 in
-
Height1.38 in
-
Weight1.08 lb
::specification::
Frequently Asked Questions
What dimming methods are built into the NPF-60D-24?
The NPF-60D-24 supports built-in 3-in-1 dimming: PWM signal, 0–10V analog, and resistance control are all natively supported without any add-on dimming module.
Can the NPF-60D-24 be used to drive dimmable 24V LED strips in a commercial museum display?
Yes. The NPF-60D-24 delivers 60W at 24V with a constant current of 2.5A, and built-in dimming makes it suitable for museum or gallery displays where adjustable light levels are essential. Its IP67 rating also protects against humidity common in climate-controlled spaces.
What is the difference between the NPF-60D-24 and the NPF-90D-24?
Both are dimmable 24V IP67 drivers with 3-in-1 dimming and the same input range, but they differ in power: NPF-60D-24 is 60W at 2.5A and measures 150.0 × 53.0 × 35.0 mm, while NPF-90D-24 is 90W at 3.75A and measures 171.0 × 63.0 × 37.5 mm. Choose based on the total wattage of the LED load.
Is the NPF-60D-24 suitable for outdoor use without a separate waterproof box?
Yes. The NPF-60D-24 is IP67-rated, so it is fully protected against dust and temporary water immersion, and its -40°C to +85°C operating range covers most outdoor climatic conditions.
What certifications does the NPF-60D-24 carry?
The NPF-60D-24 holds CB, CCC, CE, EAC, ENEC, and UL certifications and comes with a 5-year manufacturer warranty.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other NPF-60D Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well NPF-60D-54 Power Supply 60W 54V - Dimmable | 60.48W | 54V | 1.12A | IP67 | $30.83 | View |
| Mean Well NPF-60D-48 Power Supply 60W 48V - Dimmable | 60W | 48V | 1.25A | IP67 | $28.70 | View |
| Mean Well NPF-60D-42 Power Supply 60W 42V - Dimmable | 60.06W | 42V | 1.43A | IP67 | $30.83 | View |
| Mean Well NPF-60D-36 Power Supply 60W 36V - Dimmable | 60.12W | 36V | 1.67A | IP67 | $32.74 | View |
| Mean Well NPF-60D-30 Power Supply 60W 30V - Dimmable | 60W | 30V | 2A | IP67 | $30.83 | View |
| Mean Well NPF-60D-20 Power Supply 60W 20V - Dimmable | 60W | 20V | 3A | IP67 | $32.74 | View |
| Mean Well NPF-60D-15 Power Supply 60W 15V - Dimmable | 60W | 15V | 4A | IP67 | $32.74 | View |
| Mean Well NPF-60D-12 Power Supply 60W 12V - Dimmable | 60W | 12V | 5A | IP67 | $30.83 | View |
