Mean Well NPF-60D-54 Power Supply 60W 54V - Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NPF-60D-54 Power Supply 60W 54V - Dimmable
The NPF-60D is a 60W Mean Well DIN rail power converter with a 150mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 150mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750(type”HL”), CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating60.48 Watt
-
Output Voltage54 Volt
-
Rated Current1.12 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.91 in
-
Width2.09 in
-
Height1.38 in
-
Weight1.08 lb
::specification::
Frequently Asked Questions
What dimming signals does the NPF-60D-54 accept?
The NPF-60D-54 integrates 3-in-1 dimming, natively accepting PWM signal, 0–10V analog, and resistance control without requiring external dimmer modules.
Is the NPF-60D-54 appropriate for dimmable 54V LED tunnel lighting?
The NPF-60D-54 delivers 60.48W at 54V with a constant current of 1.12A and a CC voltage range of 32–54V, which covers the forward voltage range of many 54V LED tunnel or roadway lighting modules. Its IP67 rating and -40°C to +85°C range support the demanding environments of tunnel installations.
How does the NPF-60D-54 compare to the NPF-60D-48 and NPF-60D-42?
All three are 60W dimmable IP67 drivers with 3-in-1 dimming, but differ in output voltage: NPF-60D-42 is 42V at 1.43A (CC range 25–42V), NPF-60D-48 is 48V at 1.25A (CC range 28–48V), and NPF-60D-54 is 54V at 1.12A (CC range 32–54V). Match the model to the LED string’s rated forward voltage.
Can the NPF-60D-54 be installed outdoors without any enclosure?
Yes. The NPF-60D-54 is IP67-rated, providing dust-tight and temporary water immersion protection. Combined with its -40°C to +85°C operating temperature, it is designed for direct outdoor installation.
What certifications apply to the NPF-60D-54?
The NPF-60D-54 holds CB, CCC, CE, EAC, ENEC, and UL certifications and includes a 5-year manufacturer warranty.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other NPF-60D Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well NPF-60D-48 Power Supply 60W 48V - Dimmable | 60W | 48V | 1.25A | IP67 | $28.70 | View |
| Mean Well NPF-60D-42 Power Supply 60W 42V - Dimmable | 60.06W | 42V | 1.43A | IP67 | $30.83 | View |
| Mean Well NPF-60D-36 Power Supply 60W 36V - Dimmable | 60.12W | 36V | 1.67A | IP67 | $32.74 | View |
| Mean Well NPF-60D-30 Power Supply 60W 30V - Dimmable | 60W | 30V | 2A | IP67 | $30.83 | View |
| Mean Well NPF-60D-24 Power Supply 60W 24V - Dimmable | 60W | 24V | 2.5A | IP67 | $30.83 | View |
| Mean Well NPF-60D-20 Power Supply 60W 20V - Dimmable | 60W | 20V | 3A | IP67 | $32.74 | View |
| Mean Well NPF-60D-15 Power Supply 60W 15V - Dimmable | 60W | 15V | 4A | IP67 | $32.74 | View |
| Mean Well NPF-60D-12 Power Supply 60W 12V - Dimmable | 60W | 12V | 5A | IP67 | $30.83 | View |
