Mean Well ODLC-45A-1050 Power Supply 45W 1050mA (Auxiliary DC output)
The ODLC-45A is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating45.15 Watt
-
Output Voltage43 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45A-1050 for a 1050mA LED downlight?
Yes, this driver is built for constant current LED loads at 1050mA. It is a fit for LED downlights when the fixture's LED forward voltage falls within the 26-43V constant current range and the load stays within 45.15W.
Is the ODLC-45A-1050 suitable for a small high-power LED array?
It can be used for a small LED array that is designed for 1050mA constant current operation. The array voltage must stay within 26-43V, and the total load must remain within the 45.15W rating.
Can this driver power signage lighting modules?
It can work with signage modules only if those modules are constant current types rated for 1050mA. Many signage products are constant voltage instead, so this model should only be used where the module spec matches 1050mA and 26-43V.
How do I know if my LEDs are compatible with the ODLC-45A-1050?
This is a constant current driver with a 26-43V output range at 1050mA, so the LED load must be designed for constant current operation rather than constant voltage. The number of LEDs depends on each LED's forward voltage, not on a fixed LED count.
Is the ODLC-45A-1050 appropriate for wet or harsh locations?
The housing is rated IP67, so it is intended for waterproof applications where dust and water resistance are required. It is also specified for operation from -20°C to +85°C, which supports a wide range of indoor and outdoor environments.
