Mean Well ODLC-45A-1400 Power Supply 45W 1400mA (Auxiliary DC output)
The ODLC-45A is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating44.8 Watt
-
Output Voltage32 Volt
-
Rated Current1.4 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45A-1400 with a 1400mA LED downlight engine?
Yes, if the downlight is designed for constant current operation at 1400mA. The LED load also needs to fall within the 19-32V constant current range and remain within the 44.8W rating.
Is this driver a match for compact COB LED arrays?
It is a practical choice for compact COB or small LED arrays that require 1400mA constant current. Because the output range is 19-32V, it is better suited to lower-voltage constant current arrays than higher-voltage strings.
Can the ODLC-45A-1400 be used for signage light engines?
It can be used for signage light engines that are specified as 1400mA constant current loads. It is not the right choice for constant voltage signage modules, because this model regulates current rather than providing a fixed DC voltage output for the LED load.
What kind of LED load is compatible with the ODLC-45A-1400?
The LED load must be a constant current type rated for 1400mA, with a forward voltage that stays within 19-32V. The number of LEDs depends on each LED forward voltage, so it should not be selected by LED count alone.
How does the ODLC-45A-1400 compare with the other ODLC-45A models?
Within the ODLC-45A group, this model is 1400mA with a 19-32V range and 44.8W. The other ODLC-45A versions are 1050mA at 26-43V and 45.15W, 700mA at 38-64V and 44.8W, 500mA at 54-90V and 45W, and 350mA at 57-95V and 33.2W.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other ODLC-45A Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well ODLC-45A-700 Power Supply 45W 700mA (Auxiliary DC output) | 44.8W | 64V | 0.7A | IP67 | $23.34 | View |
| Mean Well ODLC-45A-500 Power Supply 45W 500mA (Auxiliary DC output) | 45W | 90V | 0.5A | IP67 | $24.63 | View |
| Mean Well ODLC-45A-350 Power Supply 45W 350mA (Auxiliary DC output) | 33.2W | 95V | 0.35A | IP67 | $25.71 | View |
| Mean Well ODLC-45A-1050 Power Supply 45W 1050mA (Auxiliary DC output) | 45.15W | 43V | 1.05A | IP67 | $24.63 | View |
