Mean Well ODLC-45A-350 Power Supply 45W 350mA (Auxiliary DC output)
The ODLC-45A is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating33.2 Watt
-
Output Voltage95 Volt
-
Rated Current0.35 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45A-350 for a long-series LED downlight or light engine?
Yes, if the fixture uses a 350mA constant current LED load. Its 57-95V constant current range makes it better suited to higher-voltage LED strings than the lower-voltage ODLC-45A models, while staying within 33.2W.
Is this driver suitable for a small LED array with higher total forward voltage?
It can be, provided the array is designed for 350mA constant current operation. The total LED forward voltage must stay within 57-95V, and the load must not exceed 33.2W.
Can the ODLC-45A-350 run signage modules?
It can only be used for signage modules or light engines that are constant current products rated at 350mA. Many signage systems are constant voltage, so this driver should be reserved for modules that explicitly match 350mA and fall within 57-95V.
How should I check LED compatibility for the ODLC-45A-350?
This driver supplies 350mA constant current across a 57-95V range, so the LED assembly must be specified for constant current rather than constant voltage. The number of LEDs depends on each LED forward voltage, which is why compatibility should be checked by total forward voltage instead of LED count.
Can the ODLC-45A-350 be used outdoors or in demanding temperatures?
The unit is rated IP67, so it is built for waterproof environments where outdoor exposure or washdown resistance matters. It is also specified for -20°C to +85°C operation, which supports use in a broad temperature range.
