Mean Well PLC-60-20 Power Supply 60W 20V - PFC
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PLC-60-20 Power Supply 60W 20V - PFC
The PLC-60 is a 60W Mean Well power converter (input range: 90~264VAC, operating temperature: -30~+50℃).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLC Series
-
Power Rating60 Watt
-
Output Voltage20 Volt
-
Rated Current3 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,PSE,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-30°C~50°C
-
Warranty2 Year
-
Length7.15 in
-
Width2.44 in
-
Height1.38 in
-
Weight0.9 lb
::specification::
Frequently Asked Questions
What is the Mean Well PLC-60-20 designed for?
The Mean Well PLC-60-20 is a 60W power supply intended for LED lighting and moving sign applications. It combines constant voltage operation with built-in constant current limiting, which makes it suited to applications that need stable 20V DC output with added protection behavior.
What are the main output specifications of the PLC-60-20?
This model is rated for 60W total output power with a 20V DC output and 3.0A rated current. It also includes adjustable output voltage and current level settings, which can help match the supply more closely to the application requirements.
Does the PLC-60-20 include power factor correction?
Yes. The PLC-60-20 has built-in active PFC, with a power factor above 0.9 at 75% load or higher. That is a useful differentiator for commercial and lighting projects where power quality matters.
What protection features are built into the Mean Well PLC-60-20?
This model includes protection for short circuit, over current, over voltage, and over temperature. It is also described as a Class 2 power unit and Pass LPS, which supports use in applications where safety compliance is an important buying consideration.
What operating environment is the PLC-60-20 rated for?
The specified operating temperature range is -30°C to 50°C. Its fully isolated plastic case also makes it a practical option for environments where a compact enclosed power supply is preferred.
Does the PLC-60-20 support dimming control?
No. The listed dimming control for this model is none. If a project requires built-in dimming functionality, this specific model may not be the right fit.
What warranty applies to the Mean Well PLC-60-20?
The listed warranty period for the PLC-60-20 is 2 years. For B2B buyers, that provides a clear baseline for support expectations when comparing this model with other LED power supply options.
