Mean Well PLC-60-48 Power Supply 60W 48V - PFC
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PLC-60-48 Power Supply 60W 48V - PFC
The PLC-60 is a 60W Mean Well power converter (input range: 90~264VAC, operating temperature: -30~+50℃).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLC Series
-
Power Rating62.4 Watt
-
Output Voltage48 Volt
-
Rated Current1.3 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,PSE,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-30°C~50°C
-
Warranty2 Year
-
Length7.15 in
-
Width2.44 in
-
Height1.38 in
-
Weight0.9 lb
::specification::
Frequently Asked Questions
What is the Mean Well PLC-60-48 designed for?
The PLC-60-48 is a 48V, 60W power supply intended for LED lighting and moving sign applications. It uses a constant voltage design with built-in constant current limiting, which makes it suitable for systems that need regulated 48V DC output with added protection behavior.
What are the main electrical ratings of the PLC-60-48?
This model is rated for 48V DC output and 1.3A rated current, with a power rating of 62.4W. It also supports universal AC input and includes active power factor correction, with PF above 0.9 at 75% load or higher.
Does the PLC-60-48 support dimming control?
No, the product data for the PLC-60-48 lists dimming control as none. Buyers needing integrated dimming should compare it with other LED driver models that specifically include dimming functions.
Is the PLC-60-48 suitable for demanding operating environments?
The PLC-60-48 is specified for operation from -30°C to 50°C, which supports use across a fairly broad temperature range. It also includes protections for short circuit, over current, over voltage, and over temperature to help support reliable operation.
What protections and compliance-oriented features does this model include?
This model includes short circuit, over current, over voltage, and over temperature protection. It is also described as a Class 2 power unit, passes LPS, and undergoes 100% full load burn-in testing.
How does the PLC-60-48 differ from a basic 48V power supply?
Compared with a basic 48V supply, the PLC-60-48 adds features aimed at LED applications, including constant current limiting, active PFC, and a fully isolated plastic case. It is positioned as a purpose-built Mean Well unit for LED lighting and moving sign use rather than a generic DC source.
What should buyers check for compatibility before choosing the PLC-60-48?
Buyers should confirm their equipment requires a 48V DC output and that the load fits within the model's 1.3A rated current and 62.4W power rating. It is best matched to applications that benefit from a constant voltage supply with built-in constant current limiting rather than models that require onboard dimming control.
