Mean Well PLD-40-1750B Power Supply 40W 1750mA
The PLD-40 is a 40W Mean Well power converter (input range: 70~108V).
Key Features
- ✓ Input voltage range: 70~108V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating40.25 Watt
-
Output Voltage23 Volt
-
Rated Current1.75 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~50°C
-
Warranty3 Year
-
Length5 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.49 lb
::specification::
Frequently Asked Questions
Can the PLD-40-1750B be used for a high-current LED downlight?
Yes, this driver is intended for constant current LED loads at 1750mA. It fits downlights whose total forward voltage is within the 13-23V CC range and whose total power draw stays within 40.25W.
Is the PLD-40-1750B suitable for dense small LED arrays?
It can be a match for dense small LED arrays that require 1750mA constant current drive. The array's combined forward voltage must stay between 13V and 23V, and it should not be treated as a constant voltage source.
Can I use this driver with compact constant current signage modules?
Yes, if the signage modules are designed for 1750mA constant current operation. The overall LED load must remain inside the 13-23V CC output window and within the 40.25W power rating.
Is the PLD-40-1750B intended for outdoor exposed locations?
No, the IP42 enclosure is better suited to protected indoor use than fully exposed outdoor conditions. It is rated for operating temperatures from -30°C to +50°C, so temperature range is broad even though ingress protection is limited.
How do I know if my LED load will work with the PLD-40-1750B?
This driver supplies constant current at 1750mA with a CC voltage range of 13-23V. The number of LEDs depends on each LED's forward voltage, so the correct match is based on the total forward voltage of the load rather than a stated LED count.
How does the PLD-40-1750B differ from other 40W PLD models?
The PLD-40-1750B provides 1750mA across 13-23V with 40.25W output. Other 40W versions include PLD-40-1400B at 1400mA, 17-29V, 40.6W; PLD-40-1050B at 1050mA, 22-38V, 39.9W; and PLD-40-700B at 700mA, 34-57V, 39.9W.
