Description
Description
Features
115VAC or 230VAC input |
Built-in active PFC function |
Fully isolated plastic case |
Constant current design |
IP42 design |
Class II power unit, no FG |
Low cost |
Protections: Short circuit / Over temperature |
Suitable for indoor LED lighting applications |
Cooling by free air convection |
3 years warranty |
General Specification
AC input voltage range | 230VAC (180 ~ 295VAC) |
AC inrush current (max.) | Cold start, 25A at 230VAC |
Withstand voltage | I / P - O / P: 3.75 k VAC |
Short circuit protection | Hiccup mode, auto-recovery |
Over Temp. Protection | 95ºC ± 10ºC (RTH1) shut down o / p voltage, re-power on to recover |
Working temperature | -30 ~ + 50ºC |
Safety standards | ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42 approved |
EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4,2, 3, 4, 5, 6, 8, 11, EN61547 |
Connection Input | H03VVH2-F 0.75mm² x2C (7.5cm) |
Connection Output | UL1430 18AWGx2C (15cm) |
Dimension (LxWxH) (mm) | 128x 60x 31.5 |
Specifications
Specifications
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating40.25 Watt
-
Output Voltage23 Volt
-
Rated Current1.75 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~50°C
-
Warranty3 Year
-
Length5 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.49 lb
