Mean Well PLD-60-1400B Power Supply 60W 1400mA
The PLD-60 is a 60W Mean Well power converter (input range: 70~108V, operating temperature: -30~+45℃).
Key Features
- ✓ Input voltage range: 70~108V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating60.2 Watt
-
Output Voltage43 Volt
-
Rated Current1.4 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty3 Year
-
Length5.04 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.75 lb
::specification::
Frequently Asked Questions
Can I use the PLD-60-1400B for a high-current LED downlight?
Yes, if the downlight is specified for 1400mA constant current and the LED load falls within the 25-43V CC range. This driver is rated at 60.2W, so it is aimed at higher-output downlight assemblies in a lower-voltage, higher-current range.
Is the PLD-60-1400B suitable for constant current signage modules?
It can work for signage modules or light engines that require 1400mA constant current and operate from 25V to 43V. It should not be used for constant voltage LED products because this unit regulates current rather than providing a fixed DC voltage.
Will the PLD-60-1400B run a compact LED array with higher current demand?
Yes, for a small LED array that is designed for 1400mA and has a combined forward voltage within 25-43V. The 60.2W output suits arrays that need more drive current while staying in a lower-voltage constant current window.
Can this model replace a 1400mA driver in an indoor commercial fixture?
It can, as long as the original driver was also a 1400mA constant current unit and the LED load operates between 25V and 43V. The physical size of 128.0 x 60.0 x 31.5 mm and the 60.2W rating should also be checked before substitution.
How do I size an LED load for the PLD-60-1400B?
The load must require 1400mA constant current and fit within the 25-43V CC voltage range. The number of LEDs depends on each LED's forward voltage, so compatibility is based on current and voltage range instead of a fixed LED quantity.
Can the PLD-60-1400B be used in indoor areas with temperature swings?
Yes, it is rated for -30°C to +45°C and uses an IP42 plastic case. That makes it suitable for indoor environments with moderate temperature variation, but not for fully exposed outdoor or high-water-ingress locations.
