Mean Well PLD-60-2000B Power Supply 60W 2000mA
The PLD-60 is a 60W Mean Well power converter (input range: 70~108V, operating temperature: -30~+45℃).
Key Features
- ✓ Input voltage range: 70~108V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating60 Watt
-
Output Voltage30 Volt
-
Rated Current2 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty3 Year
-
Length5.04 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.75 lb
::specification::
Frequently Asked Questions
Can I use the PLD-60-2000B for a COB LED downlight?
Yes, this driver is appropriate for COB or integrated LED downlights that need a constant 2000mA output and operate within an 18-30V constant current range. Its 60W rating makes it relevant for higher-output fixtures rather than small constant voltage lamps.
Will the PLD-60-2000B work for compact LED signage assemblies?
It can, provided the signage assembly is designed as a constant current 2000mA load and the total forward voltage stays between 18V and 30V. It is not intended for standard constant voltage signage products that expect a fixed DC voltage source.
Is this driver appropriate for a small high-brightness LED array?
Yes, for small high-brightness LED arrays that are specified for 2000mA constant current operation within 18-30V. The 60W output supports more demanding arrays, but the load still has to be matched to constant current rather than constant voltage operation.
How should I check LED compatibility for the PLD-60-2000B?
This model delivers 2000mA constant current with an 18-30V output range. The LED load must be a constant current design, and the usable number of LEDs in series depends on the forward voltage of each LED instead of any fixed series count.
Can the PLD-60-2000B be used in harsher indoor conditions?
Its operating temperature range is -30°C to +45°C, which supports protected indoor environments with a wide ambient range. The housing is IP42 and plastic, so it is better suited to dry or lightly exposed areas than wet locations.
