Mean Well PLD-60-2400B Power Supply 60W 2400mA
The PLD-60 is a 60W Mean Well power converter (input range: 70~108V, operating temperature: -30~+45℃).
Key Features
- ✓ Input voltage range: 70~108V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating60 Watt
-
Output Voltage25 Volt
-
Rated Current2.4 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty3 Year
-
Length5.04 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.75 lb
::specification::
Frequently Asked Questions
Can I use the PLD-60-2400B for a very high-current LED downlight?
Yes, this driver is intended for constant current LED loads that require 2400mA and operate within 15-25V. That profile fits compact high-output downlight engines more than longer, higher-voltage LED strings.
Is the PLD-60-2400B suitable for compact signage light engines?
It can be suitable for compact constant current signage light engines that need 2400mA and stay within a 15-25V forward voltage range. It is not a constant voltage supply, so it should not be matched to signage products designed around a fixed DC voltage input.
Would this driver fit a small dense LED array?
Yes, when the array is designed for 2400mA constant current operation and its electrical demand falls within 15-25V. With 60W available, it is aimed at high-output compact arrays rather than low-current multi-string products.
How do I verify whether my LEDs will work with the PLD-60-2400B?
This is a 2400mA constant current driver with a 15-25V constant current output range. The LED load must be specified for constant current use, and the number of LEDs that can be used in series depends on each LED's forward voltage rather than a stated LED count.
Is the PLD-60-2400B meant for outdoor exposure?
Its IP42 enclosure indicates limited ingress protection, so it is better suited to protected indoor or sheltered applications instead of direct weather exposure. The unit operates from -30°C to +45°C and uses a plastic case with Class II design without FG.
