Mean Well PLD-60-700B Power Supply 60W 700mA
The PLD-60 is a 60W Mean Well power converter (input range: 70~108V, operating temperature: -30~+45℃).
Key Features
- ✓ Input voltage range: 70~108V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating60.2 Watt
-
Output Voltage86 Volt
-
Rated Current0.7 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty3 Year
-
Length5.04 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.75 lb
::specification::
Frequently Asked Questions
Can I use the PLD-60-700B for an LED downlight that uses a higher series voltage?
Yes, this driver is a fit for constant current LED downlights that require 700mA and operate within a 50-86V range. Its 60.2W capacity and higher voltage range make it better suited to longer series LED configurations than lower-voltage, high-current modules.
Is the PLD-60-700B suitable for LED signage modules arranged in series?
It can be used for signage modules when the full module string is a 700mA constant current load within 50-86V. It is not a constant voltage supply, so it should be paired only with signage assemblies designed for constant current operation.
Would the PLD-60-700B work with a small LED array for display or architectural lighting?
Yes, if the array is specified for 700mA constant current and its total forward voltage falls between 50V and 86V. This model is better aligned with higher-voltage series arrays than compact low-voltage LED boards.
How do I check compatibility for the PLD-60-700B?
This driver outputs 700mA constant current over a 50-86V constant current range. Your LED load must be a constant current design, and the number of LEDs you can place in series depends on the forward voltage of each LED rather than a fixed LED count.
Can the PLD-60-700B handle colder or moderately warm indoor environments?
Its rated operating temperature range is -30°C to +45°C, which covers many protected indoor and sheltered applications. The case is IP42 and plastic, so it is better for environments where direct water exposure is not expected.
